Free samples 25mA clear lens sanan chip surface mount 0603 1608 rgb led
1,Features |
l Package ( L/W/H ) : 1.6×1.5×0.55 mm l Color : Ultra Bright BGR Full Color l Lens: Water Clear Flat Mold l EIA STD Package l Meet ROHS, Green Product l Compatible With SMT Automatic Equipment l Compatible With Infrared Reflow Solder Process |
Notes: 1. All dimensions are in millimeters ;
2. Tolerance is ± 0.10 mm unless otherwise noted.
Parameter | Symbol | Rating | Unit | ||
Power Dissipation | Pd | B | 90 | mW | |
|
| R | 90 |
| |
|
| G | 90 |
| |
Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width) | IFP | B | 100 | mA | |
|
| R | 80 |
| |
|
| G | 100 |
| |
DC Forward Current | IF | B | 30 | mA | |
|
| R | 30 |
| |
|
| G | 30 |
| |
Reverse Voltage | VR | B | 5 | V | |
|
| R | 5 |
| |
|
| G | 5 |
| |
Operating Temperature Range | Topr | -30°C ~ + 85°C | |||
Storage Temperature Range | Tstg | -40°C ~ + 90°C | |||
Soldering Condition | Tsol | Reflow soldering : 260°C For 5 Seconds Hand soldering: 300°C For 3 Seconds | |||
Electrostatic Discharge | ESD | 2000 | V | ||
2. Products View
1. Your inquiry related to our products or prices will be replied in 10 hours.
2. We have own independent R&D department on existing products for better maintenance, and still continue to develop some high-tech products. We have our own patented products.
3. Well-trained and experienced staffs to answer all your inquiries in fluent English.
4. We offer two-year’s warranty for our products and provide free technical guidance services.
For more details of 0603 rgb led and free samples, click the "send" below to contact us!
