RFID Smart Card Reader Wireless Handheld POS with GPRS and Printer,Bus Payment/Ticket Terminal

POS

SHENZHEN SEN-RICH TECHNOLOGY LIMITED

ET5000 product specifications

Item

ET5000

Content

Performance

Processor

32-Bit ARM7

Specification

SDRAM

16MB

Flash

8MB

MCU

Cortex-M4

Key Pads

20 Keys

Display Resolution

128*64 LED backlight

Security

part

Buzzer

Beep

IC Card

ISO 7816 & PBOC/EMV compliant

Features

PSAM Card

2 PSAMs +1SIM card

MSR

Track 1/2/3, bi-directional

RFiD/13.56 MHz

ISO 14443 Type A/B & ISO 18092 compliant

4 RF Indicator

Red,Yellow,Blue,Green

Audio

Audio decode

Support the WAV format audio files

Speaker

Mono 8Ω 0.5W

Thermal Printer

Printer

High speed ,Low noise

Paper roll

Width: 57mm ,Diameter: 45mm

GPRS

GSM/GPRS 850/900/1800/1900 MHz

Communication

WiFi

IEEE 802.11b/g/n

Bluetooth

Bluetooth 3.0/ 4.0+ EDR compliant

(option)

Modem

Synchronous/asynchronous transmission

Ethernet

10/100M self-adaption

Power supply

Adaptor

DC 9V/3A output

Battery

7.4V/2000mAh Li-ion

USB Device

Mini USB ×  1

Hardware

RS232

RJ11 ×  1

RS232

RJ11 ×  1

interface

Ethernet

RJ45 ×

1

DC Input

DC Jack ×  1

Environmental

Operation temp.

0℃-- 50℃

Storage temp.

-20℃--70℃

Relative humidity

10% ~ 90%, non-condensing

Font library

Support GB2312/GB18030/Unicode

Physical (L x W x H)

237*93*74(mm)

Weight

530g

Test certificate

1,PCI 4.x

2,CUP POS Security Certification

3,PBOC/EMV L1 & L2

4,qPBoC L1 & L2

5,CUP UAT
