Hot sale &Best price Reci laser tube
- 120 Set / Sets per Month
- QINGDAO
- Mini Laser Module with APC 4x8mm
- Laser Module, 15x60mm Size 405nm-850nm 8um-110um Microbeam Laser Diode Module for Laser Positioning & Pointing
- Mini laser module for laser alignment tools
- 1-5mw 520nm Low Consumption Mini Laser Diode Module 4x8mm
- 1-5mw Mini Infrared Laser Module for Measure Tools and Medical Treatment Instrument
- Mini laser module for bar code scan instrument
Product Details
Place of Origin: | Shandong, China | Brand Name: | Reci | Model Number: | 80W/100W/150W |
Product Description
Specifications
Reci laser tube1)long life cycle:8000-10000hours
2)Best Price
3)Lowest price
Reci Laser tube
Parameter:
Laser Tube Type | Laser Power(W) | Max Laser Powe(W) | Tube Length(mm) | Diameter(mm) | Beam Diameter(mm) | Catalyst | Tube work life(hour) | Warranty |
W2 | 90W | 100W | 1200 | 80 | 8 | YES | 10,000 | 8 months |
W4 | 120W | 135W | 1400 | 80 | 8 | YES | 10,000 | 8 months |
W6 | 150W | 170W | 1650 | 80 | 8 | YES | 10,000 | 8 months |
W8 | 170W | 195W | 1850 | 90 | 8 | YES | 10,000 | 8 months |
1. Installation Requirement of reci tube |
Make sure to follow the operation instructions of model W2 as shown in the illustration. The dedicated power DY10 should be equipped. The positive pole is in high voltage (the ignition voltage is 19kv). It may cause the following consequence when it is failed to follow the instruction: Arcing; the inner tube will be punctured by electricity and may cause water leakage. |
2. Operation conditions of reci tube |
1)Water cooling: using purified water; 2 to 5 liter/minute; water temperature: 10°C-40°C. 2) The operating environment: temperature 2-40°C, humidity 10-60%. 3) The working current: test current is 29mA. Maximum working current is 29mA. The running current must be kept below 27mA. The life span can reach 10,000 hours if the current is kept below 25mA. The ammeter indicating current must be connected to the negative electrode of the laser tube. 4)When it is working under over-high current for long term, the negative pole will appear light yellow, and the life span will be reduced rapidly. 5)To protect dust from going into the insulation sheath, please wrap it with plastic film. |
3. Working Performance of reci tube |
1) Cutting function. 2)Engraving function: Very good, when the working current is 4mA and the tube is in the state of preionization, the laser can be used for high-frequency impulse engra |
4. Key Notes of reci tube |
Do not clean the exterior surface of the output widow mirror with tools such as tampon; otherwise the output power will be seriously affected. The followings are the designated methods to clean up pollution in the exterior surface of window mirror: 1) When the mirror is polluted, do not turn on the laser. 2) Blow the mirror surface sideway with air blower. 3) Spray the pure alcohol on the mirror surface with sprayer. 4) Turn on the laser after the alcohol gets fully volatilized. 5) If the methods above don't work effectively, it is necessary to ask for the professional to use tampon with alcohol to clean the mirror surface from middle to edge. The best solution is to prevent the window from being polluted.
Attention: it is forbidden to clean the mirror with acetone The screw in the front and back ends of the laser tube is not allowed to be moved, otherwise the out power will be declined and even the tube may be scrapped.
Put the acryl 300mm far away from output mirror, when testing the laser spot. |
5. Safety of reci tube |
The laser beam is invisible light. Please wear protective glasses when debugging the laser. The positive pole is in high voltage. Pay attention to the security marks. |
6. Storage and Transportation Requirement of reci tube |
Pour out cooling fluid in the event of storage and transportation, and cover the output terminal with a dust-proof plastic bag. The storage environment is 2-40°C, and the requested humidity is 10-60%. Pack the laser as in the original way.
Important notes: it is requested to cement the sponge together with laser tube to prevent the tube vertically sliding during transportation. The sponge in the side of output mirror must be 70mm beyond it, and the sponge in the side of reflecting mirror must be 50mm wider. |
