13mm Brushless Long Life Small Servo Motor Made in China

13mm Brushless Long Life Small Servo Motor Made in China thumbnail-1
13mm Brushless Long Life Small Servo Motor Made in China photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Constar
Model Number:
EN1342ZWW-1-12.0
Contact Supplier Request Quote Chat Now
Constar Micromotor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Constar
Model Number EN1342ZWW-1-12.0
Usage Other, medical instrument and industrial robot and so on, medical instrument and industrial robot and so on
Certification CE, ROHS
Type Servo Motor
Torque 2mNm
Construction Other, brushless
Commutation Brushless
Protect Feature Other, *
Speed(RPM) 16500rpm
Continuous Current(A) 500mA
Output Power 4.27W
Voltage(V) 12V
Efficiency Other, 59.4

Specifications

1.brushless servo motor
2.Good quality;
3.Low noise
4.lead time 15-30 day

1.Applications:  Precision control fields like medical instrument,industrial robot and so on.



2.Operating Environment: - -15~+45°C;



3. Characteristics:

Series

Performance

Code

Dimension


(mm)

Motor Characteristics

Encoder Characteristics

voltage
(V)

Terminal resistance
(Ω)

Load torque

(mNm)

Load speed

(rpm)

Load current
(mA)

Number of channels

Counts per turn

Supply voltage

Max operating frequency

EN1342ZWW

-1

φ13*42

12

8

2.0

16500

500

2 (3)

256--1500

5(3)

60--220



4.Options:  Lead wires length, shaft length, special coils, gearheads, bearing type, encoder channels, encoder counts per turn
