16mm 24V Drone High Rpm Coreless Motor,profession Design Micro Motor
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Constar
Model Number:
1640RCG -2-24.0
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
24V No -load Speed 9500rpm Coreless Motor,performance Stable,prefession DesignNegotiableMOQ: 10 Pieces -
Diameter 16mm Length 30mm PM Long Life Electric Driving dc MotorNegotiableMOQ: 10 Pieces
-
12V 16mm Low Voltage PM Coreless Motor,micro Graphite Brush Electric MotorsNegotiableMOQ: 10 Pieces
-
16mm Precision Medical Coreless dc Motor,stable PerformanceNegotiableMOQ: 10 Pieces
-
7.4V 20mm High Speed un Manned Aerial Vehicles dc Coreless MotorsNegotiableMOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Constar
Model Number
1640RCG -2-24.0
Usage
Other, medical,health care and industrial automation., medical,health care and industrial automation.
Certification
CE, ROHS
Type
Micro Motor
Torque
8mNm
Construction
Other, precious metal commutation
Commutation
Brush
Protect Feature
Other, *
Speed(RPM)
10230rpm
Continuous Current(A)
566mA
Output Power
10.32W
Voltage(V)
24V
Efficiency
Other, *
16mm 24V drone high rpm coreless motor,profession design micro motor
1.Applications: Audio and visual products, high-end toys, personal health care products and security equipment
2.Operating Environment: -10~+60°C; 15~90%RH
3.Characteristics:
The following are our standard products, we also provide customized products and service.
Series |
Performance Code |
Commutation Structure |
Dimension (mm) |
Voltage (V) |
Termanal resistence (Ω) |
No-load Speed (rpm) |
No-load Current (mA) |
Load Torque (mNm) |
Load Speed (rpm) |
Load Current (mA) |
1640RCG |
1-12.0 |
Graphile Brush |
Φ16*40 |
12 |
8.5 |
12000 |
60 |
6.0 |
6420 |
688 |
2-24.0 |
Graphile Brush |
Φ16*40 |
24 |
13.5 |
14500 |
60 |
8.0 |
10230 |
566 |
4. Options: Lead wires length, shaft length, special coils, gearheads, encoder
