protable subwoofer sound system public power amplifier
Features:
1. This series of amplifiers are perfect protection circuit, it can adapt to poor working environment, and can can easily maintain stability. Perfect temperature protection circuit to solve the fatal damage caused by overheating.
2. When the internal temperature reaches 95°C, amplifier will automatically cut off the connection with the speaker, when the temperature dropped down to 88°C, the amplifier will automatically recover and work properly.
3. Short-circuit protection, it can ensure the engineering staffin the misues or other unexpected circumstances to protect the safety of the machine itself and the speaker, when the power amplifier overload occurs, adjust the power amplifier circuit operating condition, keep the power amplifier distortion mode of operation, thereby protecting speakers.
protable subwoofer sound system public power amplifier
Technical Parameters:
| Item | DX-1000 | DX-1200 | DX-12500 | |
| Out Power | 8Ω | 300W×2 | 400W×2 | 500W×2 |
| 4Ω | 450W×2 | 600W×2 | 750W×2 | |
| Out Power(BRIDGE) | 8Ω | 850W×1 | 1100W×1 | 1400W×1 |
| Signal to Noise | >90dB | |||
| Slew rate | >40v/US | |||
| Damping factor | 250:1 | |||
| Frequency Response | 20Hz-20KHz@±0.3dB,1W/8ohms | |||
| THD | ≤0.02% Rated Power @ 8Ω 1KHz | |||
| TMD | ≤0.03% Rated Power @ 8W | |||
| Input Sensitivity | ±1dB(0.775V/1.00V/1.4V) | |||
| Input Impedance | 10KΩ/20KΩ unbalanced or balanced | |||
| Crosstalk | ≤-75dB | |||
| LED Indication | The power indicator, signal level, clipping pressure limit | |||
| Protection | AC Fuse, DC, Short Circuit, Overheat, Overload,Softstart | |||
| Height | 2U | |||
| Weight | 12Kg | 13kg | 15Kg | |
| Dimensions | 483W×340D×88H | |||
| Item | DX-2000 | DX-2500 | DX-3000 | |
| Out Power | 8Ω | 600W×2 | 800W×2 | 1000W×2 |
| 4Ω | 900W×2 | 1150W×2 | 1450W×2 | |
| Out Power(BRIDGE) | 8Ω | 1700W×1 | 2200W×1 | 2800W×1 |
| Signal to Noise | >90dB | |||
| Slew rate | >40v/US | >45v/US | >45v/US | |
| Damping factor | 250:1 | 400:1 | 400:1 | |
| Frequency Response | 20Hz-20KHz@±0.3dB,1W/8ohms | |||
| THD | ≤0.08%(-3dB Power @ 8Ω 1KHz) | |||
| TMD | ≤0.03% Rated Power @ 8W | |||
| Input Sensitivity | ±1dB(0.775V/1.00V/1.4V) | |||
| Input Impedance | 10KΩ/20KΩ unbalanced or balanced | |||
| Crosstalk | ≤-75dB | |||
| LED Indication | The power indicator, signal level, clipping pressure limit | |||
| Protection | AC Fuse, DC, Short Circuit, Overheat, Overload,Softstart | |||
| Height | 2U | |||
| Weight | 16Kg | 17kg | 18Kg | |
| Dimensions | 483W×340D×88H | |||
protable rack mount subwoofer sound system public power amplifier
Founded in 2003, Foshan Nanhai XIBON Audio Equipment Factory is a company specializing in research and development, manufacture of professional stage power amplifier, speakers and other audio equipment. All products have passed China's compulsory product certification CCC certificates. Based on the principle of "Quality and Integrity Come First", the company's products not only occupy a certain market share for domestic audio, but also export to more than 20 countries and regions in the global market, with high international presence.
Since the company was founded, we gather a large number of well-known experts in the research and development of audio engineering, audio technology, and process design, increasingly applying international latest technologies and design concepts to the products. The factory always adheres to the idea of sustainable development and innovation. After nearly 10 years of development and growth, the factory has modernized its own manufacturing base. We have advanced automatic AI production equipment for manufacture, a fairly strong sales team for sales system, and perfect after-sales service for customers, winning their trust.
Business Process:
Inquiry ----> Drawing ----> Mould Confirmation ----> Sample Confirmation ----> Placing Order ----> Delivery
Testprogram:
3 steps test program to guarantee the quality of the product Strictly:
Inspection of raw materials+Production testing+Finished product Testing
Terms & Conditions of Trade:
1) Money Transfer; PayPal; Money Gram; Bank Transfer; Escrow; Way of payment T/T or Western Union.
2) Order's payment: T/T 30% deposit, T/T balance before delivery
3) Delivery Time: 15 to 30 days after sample confirmed & down payment.
Professional Audio Peripheral Equipment / Professional Speaker / Professional Active Speaker
(1). OEM
(2). Customize design;
(3). Top perfomance power amplifier;
(4). Mature export market all over the world
(5). Excellent performance, good quality and competitive price
(6). High efficiency toroidal transformer power supply, large high-energy linear power supply device.
(7). HI-FI machine grade material used and the topic level components, carefully selected production.
Sound structured, clear air, clean, solid driving bass speakers.
Package
5steps of packaging process, protected products from being damaged in the long distance transport:
Transparent film+ Color box+ Thick carton+ Environmental Woven bag+ Packing belt
