Home > Packaging & Printing > Packing Machinery > Filling Machine > Automatic Pre-filled Syringes Filling and Plugging Machine ZHF-S4000

Automatic Pre-filled Syringes Filling and Plugging Machine ZHF-S4000

Name: Automatic Pre-filled Syringes Filling and Plugging Machine ZHF-S4000
Brand: ZHONGHUAN
SKU: 127094149
Availability: InStock

Automatic Pre-filled Syringes Filling and Plugging Machine ZHF-S4000 thumbnail-1

Automatic Pre-filled Syringes Filling and Plugging Machine ZHF-S4000 thumbnail-2

Automatic Pre-filled Syringes Filling and Plugging Machine ZHF-S4000 photo-1

Automatic Pre-filled Syringes Filling and Plugging Machine ZHF-S4000 photo-2

US$ 200,000 - 300,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Other

Packaging Type:

Other

Contact Supplier Request Quote Chat Now

Wenzhou Zhonghuan Packaging Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Other

Packaging Type Other

Packaging Material Other

Automatic Grade Automatic

Driven Type Electric

Voltage 380/220/110 V

Power 5.5 KW

Place of Origin Zhejiang, China

Brand Name ZHONGHUAN

Model Number ZHF-S4000

Dimension(L*W*H) 3050*1600*1900 MM

Weight 950 KG

Certification GMP CE

After-sales Service Provided Engineers available to service machinery overseas

Product Description

ZHFS4000 Automatic Pre-sterilized Syringes Filling and Plugging Machine

l Automatic machine firstly developed in China by Zhonghuan. Features include automatic syringe nest-tub in-feeding, automatic paper-cover opening/throwing, automatic vacuum filling, automatic vacuum plugging and automatic nest-tub out-feeding. Accurate filling, controlling bubble during plugging. Automatic operation with monitoring all the way. Beside normal liquid, also suitable for filling transparent thick like ester acid.

l This machine is suitable to pre-sterilized syringes (SCF type) made by BD, BG, SCHOTT and major Chinese suppliers. Custom-designed is optional for other types of syringes.

l Five sync filling nozzles. Four sets of servo motor (YASUKAVVA, Japan) for accurate filling, plugging reliability and accurate row by roe moving during filling operation.

l SS rotating pumps. Filling volume set-up and accuracy tuning are executed on touch-screen without any tools.

l Siemens color touch screen. Real time monitoring and display of each operation status, vacuum pressures, nitrogen pressures, C/A pressures, fault alarm with position indication, fault indication and record. Multi-language display.

l Plugging quality is monitoring with MVS (machines vision system), to ensure higher acceptability (option).

l Process parameters can be timely printed, stored and retrievable.

l All contact parts are of SUS 316L and medical silicon rubber. Machine is coated with SUS 304 and 6061 oxidized aluminum alloy.

Technical Specifications

Filling volume	0.1-0.5ml,0.5-3ml,3-10ml,10-30ml
Number of Filling Nozzle	10 Sets
Capacity	2000-4000 Syringes/Hour
X Travel Distance	900mm
Printer	Hot-sensible printing paper, width 56mm, max. 20 alphabets per line
Machine Vision System Resolution (option)	752*480dpi
Vacuum	752*480dpi
Nitrogen	0 to -98Kpa (0 to -750mmHg)
Compressed Air	0.5-0.8mpa
Power Supply (including vacuum pump)	3P 380V/220V 50-60Hz 5.5KW
Dimension	305016001900mm (LWH)
Net Weight	950kg

Component List

No	Name	Typo	Qty	Producing Co.
1	Servo Motor	SGMAH	4	Japan YASKWA Co.
2	Driver	SGDM	4	Japan YASKWA Co.
3	Solenoid valve	SY5120	14	Japan SMC Co.
		SY5320-5LZE-01	4	Japan SMC Co.
		VCA41-5G-7-04	4	Japan SMC Co.
4	Vacuum generator	ZM131H-K5GB-E15	4	Japan SMC Co.
5	pressure sensor	ISE30A-01-D-L	2	Japan SMC Co.
5	pressure sensor	ZSE30A-01-D-L	2	Japan SMC Co.
9	Fiber Optic Sensor	E3X-ZD11	1	Japan OMRON Co
10	Photo sensor	E3Z-D61	4	Japan OMRON Co.
11	Proximity switch	E2E-X2ME1-Z 2M	2	Japan OMRON Co.
11	Proximity switch	E2E-X5ME1-Z	4	Japan OMRON Co.
13	PLC control system	CP1L-XA40DT-D	1	Japan OMRON Co.
		CP1W-40EDT	2	Japan OMRON Co.
		CPM1A-8ER	1	Japan OMRON Co.
	Temperature control	E5CZ-R2MT AC100-240	1	Japan OMRON Co.
	vision system	FZ3-300	1	Japan OMRON Co.
14	Human machine interface	NB10	1	Japan OMRON Co.
16	Regulated power supply	S-100-24	2	Taiwan MENA WELL Co.
		S-35-12	1	Taiwan MENA WELL Co.
		S-15-5	1	Taiwan MENA WELL Co.
17	Contactor	GMC-9	4	Korea LG Co.
18	Circuit Breaker	BKN-3P	2	Korea LG Co.
19	Power section switch	KCF1YZ	1	Schneider Co.
20	Push button	YWIB	3	Japan IDEC Co.
22	Annoyed button	YWIB-A4E	1	Japan IDEC Co.
