GZX Fully Automatic Water Filling Machine

GZX Fully Automatic Water Filling Machine photo-1
US$ 25,000 - 38,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Bottles
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 3P 380V
Power 1KW
Place of Origin Zhejiang, China
Brand Name ZHONGHUAN
Model Number GZX
Dimension(L*W*H) 3400*800*1900mm
Weight 3400*800*1900mm
Certification ISO9001

GZX Fully Automatic Water Filling Machines

Introduction( Automatic Water Filling Machine):

8 nozzles fill simultaneously. Number of nozzles can be increased according to requirement.

Rapid cleaning, rapid adjustment, stepless adjustment of speed for volume cylinder, suitable for filling of different specification and different liquid.

Only one adjustment necessary for filling quantity, micro-adjustment for each volume cylinder, high precision and good consistency of filling.

Contact material parts is 316L stainless steel and silicone rubber, in conformity with GMP standard.

Filling piston cylinder controlled by stepless speed adjustment of imported speed reducing motor, suitable for aqueous liquid and viscous liquid.

Inertia eliminated by imported electro-magnetic clutch and brake, high precision of filling.

Man machine interface and PLC communication. Only simple setting on screen is necessary for commissioning equipment and changing types.

Bottle charging, positioning, filling, and bottle discharging are all automatic, if the bottle is not on the right position, the bottle is blocked, or the filling pipe is not inserted into the bottle when filling, the equipment will protect automatically and continue to operate after eliminating the trouble.



Technical Parameter( Automatic Water Filling Machine):

Model

GZX200

GZX500

GZX1000

Filling Capacity

15-220ml

90-520ml

300-1100ml

Number tube

8Set

8Set

8Set

Filling Speed

40-60b/min

40-55b/min

40-55b/min

Power

0.75 KW

1KW

1.5 KW

Power Supply

3P 380V

3P 380V

3P 380V

Air Pressure

3-5Kg/cm2

3-5Kg/cm2

3-5Kg/cm2

Dimension (L×W×H)

3400×800×1900mm

3400×800×1900mm

3400×800×1900mm
