12 Heads Full-automatic Anticorrosive Filling Machine

12 Heads Full-automatic anticorrosive liquid filling machine

1,Power supply:220V 50HZ

2,power:1.5Kw

3,production speed:1000-2500 bottles/hour

4,air source:0.33~0.50Mpa  stable air source

5,weight:480kg

6,dimension:2000mm ×1100mm ×2500 mm

Main features( anticorrosive filling machine):

The series filling machine is a kind of full-anticorrosive (PLC) program controlled high-tech  filling  machine  with  photoelectric  sensing  and  pneumatic  actuating

researched and developed by our company. The machine is specially used for filling strong corrosive liquids and liquids such as cosmetics that can't contact the metal. The parts of the machine that contact the liquids are all made of nonmetal anticorrosive materials. It is designed with submersible filling function, featured by accurate measurement and no bubble and dropping during the filing.

The electric/pneumatic parts( anticorrosive liquid filling machine) :

1,The principle of suction back device:

This device is mainly designed for filling machine. When finishing the filling, PLC delivers signal, the back suction device opens the valve, forms negative pressure. This can ensure the liquid on filling nozzle can not drop on the bottle mouth and conveyor.
