Model CCG1000-12D Intellectualized viscous paste filling machine
Applicable Material: seed coating, SC, Cream high-viscosity materials etc.
1. Accurate measurement: The servo control system to ensure that the total can reach a constant position of the piston.
2. Variable speed filling: In the filling process, when close to the target filling volume to achieve a slow speed can be applied when filling, to prevent fluid overflow bottle pollution.
3. To facilitate the adjustment: Replacement of filling in the specifications only in the touch screen you can change the parameters, and all the filling for the first time changes in place.
Fine-tune the dose on touch screen to adjust.
· Apply to the bottle diameter |
Φ40-100 mm |
· Height for bottle |
80-230mm |
· Measure precision |
±1%(≤200ml),±0.5%(200-1000 ml) |
· Volume |
80~1000 ml |
· Production capacity |
≤5400 b/h |
· Air pressure |
0.5-0.7 Mpa |
· Amount of Air-consuming |
200 l/min |
· Power source |
~220 V,50 Hz |
· Total power |
2.5 KW |
· Weight |
about 900 kg |
· External dimensions |
2000×1050×2300(L×W×H) mm |
