Home > Transportation > Tractor & Parts > Tractor > 10Hp Walking Tractor SH101

10Hp Walking Tractor SH101

10Hp Walking Tractor SH101 thumbnail-1
10Hp Walking Tractor SH101 photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Walking Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Jinhua Jufeng Economy & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Walking Tractor
By wheel 2WD
Usage Farm Tractor
Certificate Other
Brand Name G-max
Model Number SH101
Place of Origin Zhejiang, China

Specifications

1.8~20hp
2.1-Cylinder&Diesel Engine&Evaporation
3.6+2shift
4.Pull&Drive
5.Attached Rotary Tiller,Disc Plough

Model

Unit

SH101

Structure weight

Without rotavator

kg

270



With rotavator



325

Overall dimensions (LxWxH)

mm

2180×910×1060

Number of blades

PCS

1

Rototilling width

mm

800

Type of tractor



Single axle, dual-purpose for both traction & drive

Travelling speed

Forword

Km/h

1.98, 3.08, 4.98, 8.04, 12.49, 20.2



Reverse



1.53, 6.18

Type size



6.00-12

Wheel track

mm

680~740(adjustable)

Min. ground clearance

mm

210

Min. turning radius

m

0.71 (without rotavator)

Model of engine



185N

Type of engine



Horizontal 4-stroke

Bore x stroke

mm

85×90

Total displacement

L

0.511

Compression ratio



21:01

Turing speed of crankshaft

rpm

2300

1-hour rated output

KW/hp

7.0/9.5

12-hour rated output

KW/hp

5.88/8

Specific fuel consumption

g/kw.h

≤273.4

Specific lube oil consumption

g/kw.h

≤2.72

Cooling mode



Condenser (Radiator)

Main farm implements (optional)

Anti-skid steel wheel Model
Single-furrow plough Model 1LS-125
Turnover plough
Rotary tiller Model 80D-1
Sprinkler Model
Swather/reaper Model 4GL-100
Trailer 7C-0.8 (Standard)

This walking tractor is of dual-function type that can be used as a means of traction as well as drive. It is featured by its simple and compact structure, good reliability, long service life, easy operation, ample output, light weight and good cross-country ability. And the gear-box is in horizontal type which may lead to better equilibrium ratio. It is very suitable for use in paddy fields, dry fields, orchards, vegetable gardens and hilly land with a little inclination. It can be used for plough rotary tilling, harrowing in paddy fields, harvesting, drilling, ditching, transportation and etc. if suitable farm implements or accessories are attached. In addition, it can also be extensively used as a stationary power source for small scale drainage and irrigation, sprinkling, grain threshing, cotton ginning, flour milling, fodder cutting and so on.
