Eye Drop Filling Stoppering And Capping Machine

Eye Drop Filling Stoppering And Capping Machine photo-1
US$ 20,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Medical, Chemical
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Medical, Chemical
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 2KW
Place of Origin Shanghai, China
Brand Name Shengsen
Model Number SS-1842
Dimension(L*W*H) 2000(L)*1500(W)*2000(H) mm
Weight 600KG
Certification GMP
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.eye drop filling machine
2.Peristaltic pump
3.touch screen control
4.Speed:30-80bottles/min
40 days delivery time

 Eye drop filling stoppering and capping machine



 Brief Introduction:

1.The machine is used for filling,stoppering and capping for 2-30ml plastic or glass eye drop bottles.

2. Adopt high accurate cam with indexing mechanism to finish index plate,positioning,stopper putting and cap putting

3. The cosine acceleration cam drive makes screw-capping nozzle up and down

4. Constant torque screw–capping nozzle is adopted;creep pump or ceramic pump is   used for metering filling.

5. Touch screen control system, and stop filling, stoppering and capping if no bottles

6. Accurate position, stable transmission, cap protection, accurate metering and easy operation



Main Technical Parameters:

Yield Capacity

 30-40 bottle/min  (1 filling nozzle)

 60-80 bottle/min(2 filling nozzles)

Power Supply

 380V,  50HZ

Power

2KW

Air Supply

 10-20M³/H , 0.3-0.4kg/cm³

Dimension

 2000(L)×1500(W)×2000(H) mm

Weight

 600KG

 Filling accuracy

 99.8%

 Pump

 peristaltic pump(ceramic pump)

 Capping rate

 99.8%
