Alloy 3105 Coated Aluminium Steel Coil

US$ 3,000 - 3,900 MOQ: 5 Metric Tons

Key Specifications

Grade:

3000 Series

Temper:

O-H112

Type:

Coil

Henan Huawei Aluminum Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Tianjin or other

Delivery Detail:

Delivery time depends on order quantity.

Grade 3000 Series

Temper O-H112

Type Coil

Application roofing,aluminum composite panels,...

Thickness 0.2-1.2mm

Width max 1600mm

Surface Treatment Coated

Alloy Or Not Is Alloy

Place of Origin Henan, China

Brand Name HW

Model Number A1100,A1050,A3003,A3005,A3104,A3105,A5052,A5182,A8011,etc.

Specifications

Alloy 3105 coated aluminum steel coil
1.Alloy: 1100,1050,3003,3005,3105
2.Thickness: 0.2-1.2mm
3.Max Width: 1600mm
4.PE&PVDF

Alloy 3105 coated aluminium steel coil

Alloy	A1100,A1050,A3003,A3005,A3104,A3105
Temper	H14
Thickness	From 0.2mm to 1.2mm
Width	Standard width:1240mm
Width	Max width:1600mm
Diameter	Standard dia:1200mm
Diameter	Interior dia:75mm,150mm,405mm,505mm
Weight	2.5 T/coil,3.0 T/coil
Coating	PE,PVDF
Surface	Mill Finished, Coated, Embossed, Brushed
Color	various
Gloss	10-90%
Coating Thickness	PE: 18-25 micron
Coating Thickness	PVDF: 25 micron
Coating Hardness (pencil resistance)	More than 2HB
Coating adhesion	5J
Impact Resistance	No peeling or cracking
Flexibility(T-bend)	2T
MEK resistance	More than 100
Out package	Wooden splint with export standard
Application	Cans cover ring, ACP, wall cladding, facades, roofs and canopies, ceilings, signboards, blind window, display platforms, electrical panels, etc
