Vibration damper for cable clamp

Specifications

Vibration damper for cable clamp

Materials

Hammer:Be made of Hot Galvanized Iron.

Suspension line:19 shares a special galvanized steel strand.

Clamp:Aluminum  Alloy.

Preformed armour rods:Aluminum Alloy.

Introduction&Application of vibration damper

Damper (VSD) by a certain weight, the size of the hammer, high elasticity, high strength galvanized steel wire and high strength aluminum alloy clamp, etc.Parts. Cover wide frequency range, high power dissipation of energy, can effectively lead breeze vibration of dissipation of energy, reduce the vibration levels of lead, extend long wire life. Can be directly installed on the wire, when installed in the overhead ground wire composite (OPGW) on, the need to install the damper on the special care lines.

Consideration

1.Such as the damper installation location falls within the twisted wire on, you do not care lines installed directly to the installation.

2.If the calculated vibration damper cable installation position falls on, you need to protect installation of lines, and pay attention to retaining the end of the line distance of at least the end of twisted wire 50mm.

3.If the calculated vibration damper installation location falls outside the twisted wire on, you can shift a little, direct installation, including twisted wire, but outside the twisted wire from the vibration center of the end of more than 50mm.

4.Hammer towards: sledgehammer head-pole side.
