ACP Sheet for Interior and Exterior Wall Cladding
US$ 2 - 30
MOQ: 1000 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Huawei
Model Number:
HP18
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2mm-8mm Exterior Wood Wall Panels,aluminium Composite Material(acm), Aluminium Composite Panel/acp SheetUS$ 2 - 30MOQ: 1000 Square Meters -
Aluminium Composite Material(acm)US$ 2 - 30MOQ: 1000 Square Meters
-
2mm-8mm Exterior Wood Wall Panels,aluminium Composite Material(acm), Aluminium Composite Panel/acp SheetUS$ 2 - 30MOQ: 1000 Square Meters
-
ACP Wall Cladding SheetUS$ 2 - 30MOQ: 1000 Square Meters
-
Wood Pattern Aluminium Composite Panel SheetUS$ 2 - 30MOQ: 1000 Square Meters
Place of Origin
Henan, China
Brand Name
Huawei
Model Number
HP18
Usage
Outdoor
Function
Anti-Static, Antibacterial, Fireproof, Mould-Proof
Surface Treatment
Anodized, Brushed, Mirror, PE Coated, PVDF Coated
Specifications
exterior wood wall panels1.ACP/ACM,
2.Good Performance,
3.Customized size,
4.Standard Package.
Exterior wood wall panels
1.ACP/ACM,
2.Good Performance,
3.Customized size,
4.Standard Package.
Anodized ACP panel, mirror finish aluminum composite panel sheet
Name |
Aluminium Composite Panel |
|
Brand |
Yaguan |
|
Thickness of pannel |
2mm, 3mm, 4mm, 5mm, 6mm |
|
Thickness of aluminium |
0.05mm-0.6mm |
|
Coating |
PE & PVDF |
|
Specification |
Standard size |
1220mm×2440mm |
Non-standard width |
1250mm,1500mm,1570mm etc. |
|
Max length |
6000mm |
|
Special Size |
According to client’s request |
|
Usage Scope |
Interior |
kitchen Walls ,Curtain walls, ceiling,suspended ceiling etc. |
Exterior |
building decoration ,sign,billboard,railway,airpoart etc. |
|
Advantages |
Self cleaning property |
|
Anti-contamination property | ||
Easy cleaning property | ||
Products standard |
GB/T17748-1999 |
|
Feature :
-Light weight, high strength, extreme rigidity, superior impact resistance,
-excellent surface flatness and smoothness ,
-heat insulation, sound insulation, fire-resistance,
-acid-resistance, alkali-resistance, good weatherproofing and non-resonance
-various uniform colors ,can be easily processed and fabricated, quickly installed,
-elegant and magnificent, good flexibility fits various designs,
-easily maintenance, simply cleaning
Applications:
1. Constructional exterior curtain walls;
2.Decorative renovation for storey-added old buildings;
3. Indoors decoration for interior walls, ceilings, bathrooms, kitchens and balconies;
4.Advertisement board, display platforms and signboards;
5. Wallboard and ceilings for tunnels;
6. Raw materials in industrial purpose;
7. Materials used for vehicle and boat.
Package:
Plastic protection film, full container, loading directly bulk cargo with pallets.
Colors
Standard color of RAL and any other colors can be customized at clients' request.
Surface properties :
Paint Thickness(micron) |
Anodize |
Pencil Hardness |
2H |
Toughness Of Coating |
2T |
Temperature Resistance |
-500C+900C |
Impact Strength(kg/cm2) |
50 |
Boiling Water Resistance |
boiling for 2 hours,No change |
Acid Resistance |
Immerse surface in 2% HC1 for 24hours,No change |
Alkali Resistance |
Immerse surface in 2% NAOH for 24hours,No change |
Oil Resistance |
Immerse surface in 20# engine oil for 24hours,No change |
Solvent Resistance |
Cleaned 100 times with Dimethylbenzene,No change |
Cleaning Resistance |
>1000 times no change |
Thermal Expansion |
2.4mm/m @1000C Temp difference |
Peel Strength |
Average 131N.mm/mm |
Bending Strength |
>100MPA |
Bending Elastic Modules |
>2.0*104MPA |
Heat Distortion Temperature |
>950C |
