High quality water filling machine

Name: High quality water filling machine
Brand: Sunstar
Price: USD $16,000 - 89,000 / Set

FOB Price

USD $16,000 - $89,000 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port Shanghai
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Application:	Beverage, Chemical	Packaging Type:	Bottles
Packaging Material:	Glass, Plastic	Automatic Grade:	Automatic	Driven Type:	Electric
Voltage:	380V, 50HZ	Power:	3.5kw	Place of Origin:	Jiangsu, China
Brand Name:	Sunstar	Model Number:	CGF	Dimension(LWH):	330025002800mm
Weight:	4500kg	Certification:	CE ISO	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

water filling machine

Table water bottle filling machine / equipment / production line

1.Capacity:2000-36000b/h. 2.Bottle Specifications:H=170-340ml

Table water bottle filling machine / equipment / production line is suitable filling water,working steable with famous electrical components and working very stable

CGF Wash-filling-capping 3-in-1unit

Products Introduction:

This CGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled mineral water, purified water, alcoholic beverage machinery and other non-gas beverage machinery. The CGF Wash-filling-capping 3-in-1unit:Beverage Machinery can finish all the process such as press bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.

Juice Bottling Machine / Mineral Water Production Line-Equipment characteristics: 1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier. 2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough.. 3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution. 4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose. 5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains. 6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.

Water filling Machine model detail

Technical Data
Model	CGF14/12/4	CGF18/18/6	CGF24/24/8	CGF32/32/10
The number of Washing, Filling, Capping	14-12-4	18-18-6	24-24-8	32-32-8
Producing capacity; The number of bottle(600ml)/hour	2000-4000	5000-7000	8000-12000	12000-15000
Applicable bottle specifications (mm)	φ=50-108 H=170-340 330ml-2.25L
Pressure (kg/cm2)	2~3
Motor power (kw)	Main motor 1.5kw	Main motor 2.2kw	Main motor 3kw	Main motor 4kw
Outside vacuum pump power (kw)	0.75	1.1	1.5	2.2
Overall dimension (mm) (LxWxH)	2100x1400x2500	2460x1720x2650	3100x2100x2650	3500x2500x2650
Weight(kg)	2500	3500	4200	5500

Technical Data
Model	CGF40/40/10	CGF48/48/12	CGF60/60/15
The number of Washing, Filling, Capping	40-40-10	48-48-12	60-60-15
Producing capacity: The number of bottle(600ml)/hour	16000-20000	20000-24000	25000-30000
Applicable bottle specifications (mm)	φ=50-108 H=170-340 330ml-2.25L
Pressure (kg/cm2)	2~3
Motor power (kw)	Main motor 7.5kw	Main motor 9.5kw	Main motor 12kw
Outside vacuum pump power (kw)	2.2	3	4
Overall dimension (mm) (LxWxH)	4600x1800x2650	5200x4500x3400	6500x4500x3400
Weight(kg)	6800	7600	9800

Production Flow

Mineral/pure water production line:

Pure water/mineral water treatment system--- filling 3in1 ---labeling--- code printer---film packing or carton----end product

We can provide whole mineral water/pure water production line

Associated Brands

Our Services

Service idea

Serve attentively and pass the truth. Put oneself in the position, feel the grateful in the heart. From the rigor and efficiency of design research and development to the perfect reproduction of manufacturing process, and to the tight on-site installation and debugging, Sunstar Machinery unites and strives to play the strongest voice of the industry. Keeping pace with the times and stepping forward self-motivated, Sunstar plans the layout to help the customers achieve and go beyond dream according to the customer's actual situation and the characteristics of products constantly.

Serves every moment; Serves with all the heart

Turnkey project

We can supply turnkey project of water, juice/tea, carbonated drink etc filling and packing production line for customer. Sunstar will supply excellent equipment, perfect service for customer to save time and money. Think what the customers’ thinking, do what the customers urgently want.We want to establish long-term win-win cooperation relation with customer. Come on, friends!

After-sales service

After-sales service is implemented according to the international general standard.

1. 1 year guarantee and life-long service, the after-sales service website, hotline and fax within 24 hours are available and arrival at appointed place within 72 hours (domestic) is fulfilled.

2. Always prepare rapid wear, consumable, and important spare parts in spare part warehouse to give customer a reply in the first time.

3. Pay regular return visits for every customer to solve the hidden troubles in their equipment and provide the latest equipment information and keep records and files.

4. Qualified skilled service team completes after-sales services for every customer in a timely fashion.

Certifications

Processing Equipment

This is our main processing equipment for bottled/canned water/CSD/juice/beer/oil etc liquid filling and packing machine production line
