Bottle PE Film Shrink Packing Machine
Product introduction:
Bottle PE Film Shrink Packing Machine---The machine was used for pack 6 bottles/cans, 12 bottles/cans, 24 bottles/cans into one group with PE film. The bottle PE film shrink packing machine is last one of the beverage production line. The shrink packing machine’s instruction as following:
1. Invert speed control.
2. Bottle entering, Auto unscrambling bottle, Pushing bottle, Heat sealing-Saw cutting, Pressing PE, Shrink, Cooling.
3. This machine applies air-stirring mechanism in pushing bottle and hot sealing-cool cutting. It uses flat silk pulse seal, the saw tooth knife cuts, The unique heat seal-cool cut mechanism, has guaranteed the packing agglutination, reliable, and artistic.
4. Automatic unscrambling bottle's appliance makes bottle changing more quickly and conveniently.
5. Delivering film mechanism and the tensity voluntarily adjusts.
6. PLC programmable procedure control system.
7. Double air blowers, guarantees the temperature balance in the shrink stove with PAD temperature controller, that apparently saves energy.
8. It applies wing shape stainless steel heating system, which is durable for long time use.
9. The heatproof Bolivian filament special fluorine dragon transportation net belt is used in shrink part to ensure the steady of transportation and high strengthen wear proof.
10. This machine applies invert speed control net belt conveying mechanism.
11. The height of the conveyer shall be made towards client's demand.
12. The direction of bottle entering can be adjusted according to client's demand
13, according customer request, can make the stainless steel belt inside the shrink tunnel instead of plastic belt
Technical parameter:
Model: SP-10
Packaging speed: 8-12Packages/minute
Thermal shrinkage passage dimension: L1800mm× W650mm× H450mm
Max. Package dimension: L600mm× W400mm× H350mm
Transfer belt dimension: 800-1200mm
Sealing and cut time: 0.5-1.5s
Shrinking temperature: 140-160°C
Operating air pressure: 0.6-0.8Mpa
Air consumption: 0.5m3/minute
Operating power supply/power: 380V,19KW
Dimension for the whole unit: L5500mm× W3200mm× H2100mm
Product name:
Shrink packing machine, PE film shrink packing machine, bottle packing machine, film packing machine, film shrink packing machine
Product details picture:
PE film shrink packing machine main machine
The bottom of PE film shrink packing machine
Shrink tunnel of shrink packing machine
PE shrink packed bottle
....
