Glass Bottle Beer Filling Machine BCGF18-18-6

Glass Bottle Beer Filling Machine BCGF18-18-6 photo-1
US$ 30,000 - 78,600 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Commodity
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of china
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage, Commodity
Packaging Type Bottles
Packaging Material Glass, Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage according to customer's requirement
Power 1.5-5.6kw
Place of Origin Jiangsu, China
Brand Name Sunstar
Model Number glass bottle beer machine
Dimension(L*W*H) 2200*1300*2500mm
Weight 2000-4000kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Glass Bottle Beer Filling Machine BCGF18-18-6



Product introduction of glass bottle beer filling machine:

Glass bottle beer filling machine was used for filling beer into glass bottle and seal it by crown cap.

The glass bottle beer filling machine was combined with glass bottle washing, beer filling and crown capping machine into one body. The guiding shaft for bottle positioning with bottle support, stable bottle feed and discharge.





The features of glass bottle beer filling machine:

The controlling theory for the high pressure foaming injection system.

The high pressure forming injection system(induced bubble device) can reduce the air into beer bottle to use foam. So the beer will be more purity and fresh.

The beer filler height adjustable and crowner heads for different height of bottle. Designed cap hopper and transporter, less cap distortion, simpler structure and easier for cleaning.

The crowner can be fully decrease the bacterial pollution.

Fast change over parts, such as push bottle screw, star wheel and guiding board.

Programmable controller automatically controls the filling steps, cullet flushing, filling valve opening/closing. High pressure foaming. It is a good beer machine for small and middle beer maker.







Technical parameter of glass bottle beer filling machine:



Model

BCGF16-12-6

BCGF18-18-6

BCGF24-24-6

BCGF32-32-8

Capacity(bph)

1000-1500

2000-3000

4000-5000

6000-8000

Bottle material

Glass bottle

Feed bottle

Feeding bottle screw

Cap type

Crown cap

Bottle volume

0.2-1.5L

Bottle size

D: 40-90mm H:170-330mm

Total power

1.5kw

1.75kw

3.75kw

5.6kw

Dimension(mm)

2200*1200*2500

2230*1300*2500

2300*1600*2500

2400*1900*2500

Weight (kg)

2200

2400

3200

3600







Glass bottle beer filling machine picture:

Glass Bottle Beer Filling Machine BCGF18-18-6

Filling for beer





Glass Bottle Beer Filling Machine BCGF18-18-6

Beer filling





Glass Bottle Beer Filling Machine BCGF18-18-6



Glass bottle washing



Glass Bottle Beer Filling Machine BCGF18-18-6



Beer washing filling capping 3in1 monoblock

Glass Bottle Beer Filling Machine BCGF18-18-6

 Forming device





Glass Bottle Beer Filling Machine BCGF18-18-6





The electric component of glass bottle beer filling machine:

Glass Bottle Beer Filling Machine BCGF18-18-6

....
