Specifications
HY380 Mini Loader is multifunctional.It has high efficiency,powerful momentum,flexible operation.Its min turning radius is 1.
Compact utility HY380 Mini Loader is a new minitype multifunctional machine with advanced performance.
Specification of HY380 Mini Loader
Item |
HY380 |
|||
|
Engine |
Rated Power(Kw) |
14.9Kw(20Hp) |
||
Rotating speed(rpm) |
3600 |
|||
Noise (dB) |
≤95 |
|||
|
Hydraulic System
|
Pressure(Mpa) |
17 |
||
Cycle Time (s) |
Raise |
Dump |
Lower |
|
4.27 |
1.34 |
3.31 |
||
|
Performance |
Operating Load (Kg) |
200 |
||
Bucket capacity (m3) |
0.15 |
|||
Max Lifting Force(Kg) |
375 |
|||
Speed (Km/h) |
0-5.5 |
|||
Operating weight(Kg) |
940 |
|||
Fuel tank(L) |
21 |
|||
Hydraulic oil tank(L) |
27 |
|||
Tyre |
16*6-8 |
|||
Dimension of HY380 Mini Loader
Item |
HY380 |
Max. height (mm) |
2112 |
Dump height(mm) |
1460 |
Overall height (mm) |
1205 |
Overall length with bucket(mm) |
2206 |
Dump distance (mm) |
388 |
Overall Length without bucket(mm) |
1752 |
Bucket width(mm) |
980 |
Overall length to outside of tyre(mm) |
1033 |
Ground clearance(mm) |
90 |
Clearance circuit front (mm) |
1307 |
Dump angle at max height |
30° |
Max attachment rollback when bucket on ground |
25° |
