Inspection Camera
Model: MFL14000KPA
Standard C-Mount camera with Aptina CMOS sensor;
With hardware resolution among 1.2M to 14M;
On-board memory for perfect synchronization,higher frame rate and stable performance;
High performance cooling structure, ensures low image noise;
USB2.0 interface ensuring high speed data transmission;
Ultra-Fine color engine with perfect color reproduction capability;
With advanced video & image processing application MindfullView;
Providing Windows/Linux/OSX multiple platform SDK;
Native C/C++, C#, DirectShow, Twain Control API; Luxurious USB2.0 CMOS camera with frame buffers and it adopts ultra-high performance CMOS sensor as the image-picking device,and USB2.0 is used as the data transfer interface.
Can be widely used in brightfield environment and microscope image capture and analysis with moderate speed.
Main Parameter
| Sensor & Size(mm) | MT9F002(C) 1/2.3"(6.451x4.603) |
| Pixel(μm) | 1.4*1.4 |
| G Responsivity/Dynamic range/SNRmax |
0.724v/lux-sec 65.3dB 35.5dB |
| FPS/Resolution |
2.7@4096x3288 10@2048x1644 35@1024x822 |
| Binning | 1*1,2*2,4*4 |
| Exposure | 0.4ms~2000ms |
Operating Temperature |
-10℃~ 50℃ |
Storage Temperature |
10℃~ 60℃ |
Operating Humidity |
30~80%RH |
Spectral Range |
380-650nm (with IR-filter) |
White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
Color Rendering Technique |
Ultra Fine Color Engine |
Capture/Control API |
Native C/C++, C#/VB.NET, Directshow, Twain, Labview |
