Refractory Mullite,alumina Ceramic

Refractory Mullite,alumina Ceramic photo-1
US$ 100 - 10,000 MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Shape:
Brick, brick
Material:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Material Other
Model Number FLZ--031
Brand Name Fameris, Famerise
SiO2 Content (%) 2%

Specifications

1.ISO 9001:2000
2.Extra fine quality with competitive price
3. high temperature resistance, working temperature above 1700

Features:

1) A variety of specifications available.

2) Satisfy various technical request

3) Lower medium spoilage

4) Good insulation performance and high temperature resistance

5) Stiffness texture

6) Used in all electric products, electric heating products and wear resistant machinery parts.



The ceramic electronic components: low loss at high frequency. Good insulating , high strength, , low dielectric constant, Great mechanical strength, high air tightness, high chemical stability, etc. We can produce all kinds of ceramic holders, Ceramic seal,ceramic substrate, ceramic tubes, ceramic pipe, ceramic ring,ceramic plate,Ceramic side bar, ceramic plunger, etc. Widely used in electronic components, electronic device and electric products. Our products meet the international standards.



Serial number

performance index

Measuring unit

High purity alumina

Alumina

High alumina

1

Al2O3

%

99.7

99.3

85

2

SiO2

%

less than0.1

3

Density

g/cm3

3.95

3.88

3.2

4

Water absorption

%

0

0.01

0.2

5

Cold compressive strength

MPa

450

350

200

6

20 degree Celsius leak rates

Torr/L.sec

less than10-11

less than10-11

less than10-11

7

Twisting in high temperature

mm

1700 degree Celsius 0.2 allowance

1600 degree Celsius 0.2 allowance

1400 degree Celsius 0.2 allowance

8

Bonding in high temperature



1700 degree Celsius non-caked

1600 degree Celsius non-caked

1400 degree Celsius non-caked

9

20—1000 degree Celsius coefficient of

thermal expansion

mm.10-6/degree Celsius.m

8.6

8.2

8.2

10

Thermal conductivity

W/m.k

25

25

25

11

Electric insulation strength

KV/mm

20

20

15

12

20 degree Celsius direct current

insulating resistance

Ohm/cm

1014

1014

1014

13

High-temperature

insulation resistance

1000 degree Celsius MΩ

≥0.08

≥0.08

≥0.08

1300 degree Celsius MΩ

≥0.02

≥0.02

≥0.02

14

Thermal shock resistance



1550 degree Celsius 6 times not cracked

1550 degree Celsius 6 times not cracked

1300 degree Celsius 3 times not cracked

15

Maximum service temperature

degree Celsius

1900

1800



Packaging & Shipping
Packaging Detail: Standard Export Carton or As Customers' Request
Delivery Detail: 30 Days After Samples Confirmed and Deposit Receipt

Our Services

1. For customers with good credit, We presented a small gift with Chinese characteristics.

2. We offer a warm and thoughtful service




Company Information

  Our brand name is FAMERISE. We have many years of experience in the export flange.our product have passed ISO certification and a series of international certification. Our plant capacity is also very strong,10000 ton/month, will not affect the delivery time. We have a strong research and design team. Our products are exported all over the world and praised around the world. We look forward to exchanges and cooperation with customers sincerely.

  Product pictures

refractory mullite,alumina ceramic


FAQ




1.Would you please send us some samples?

 Reply: Our company can provide  samples. However, the frieght should be born by the clients. In particular case, if the mould is required to be made first for some special shaped sample, the mould cost and sample fees assumed by clients will be highly appreciated.

2. How long is the service life?

Reply: According to affliated with usage methods, operation frequency, etc.

3. What's the color of your products?

Reply: Different sample are featuring with different colors, You may send the specification and requirements to us, our technician and factory will provide you with pictures and specific solutions.

4.We are interested in your products, please give the details to me.

Thank you for your letter. Firstly we want to introduce our company--We are a professional manufacturer of pipefitting mainly used in industry . If you have any questions,you can contact us,we will try to solve your problem.
