Industrial Alumina Ceramic Boat

Industrial Alumina Ceramic Boat thumbnail-1
Industrial Alumina Ceramic Boat thumbnail-2
Industrial Alumina Ceramic Boat thumbnail-3
Industrial Alumina Ceramic Boat thumbnail-4
Industrial Alumina Ceramic Boat thumbnail-5
Industrial Alumina Ceramic Boat thumbnail-6
Industrial Alumina Ceramic Boat photo-1
Industrial Alumina Ceramic Boat photo-2
Industrial Alumina Ceramic Boat photo-3
Industrial Alumina Ceramic Boat photo-4
Industrial Alumina Ceramic Boat photo-5
Industrial Alumina Ceramic Boat photo-6
US$ 0.5 - 2 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Type:
Ceramic Parts
Application:
Industrial Ceramic
Contact Supplier Request Quote Chat Now
Qingdao Fame Rise Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Type Ceramic Parts
Application Industrial Ceramic
Material Alumina Ceramic
Model Number ceramic boat
Brand Name Fame Rise



Product Description



ceramic boat specifications are as follows: 1,

characteristics Items Types
SS-C-1100 SS-C-1200S SS-E-1250 SS-F-1300
Physical Properties Bulk Density(g/cm3) 2.3~2.5 2.5~2.7 2.5~2.7 2.5~2.7
Straightness <0.07%*L <0.07%*L <0.07%*L <0.07%*L
Apparent Porosity(%) 20~25 17~22 17~22 15~20
Water Absorption(%) 8~10 6~8 6~8 6~8
Bending Strength       (Mpa) Room Temp. 40~50 45~55 45~55 60~67
High Temp.(1300°C) >20 >30 >40 >40
Thermal Expansion Coefficient                                  (×10-6/°C)(25-1000°C)                  5.5~5.7 5.7~6.0 5.6~5.9 5.7~6.0
Thermal Shock Resistance Good Excellent Very good Very good
Max.Working Temp.(°C) 1100 1200 1250 1300
Chemical  Composition Al2O3(%) 65~68 74~76 74~76 70~72
SiO2(%) 25~27 22~24 22~24 21~23
ZrO2(%) - - - 4~7
Application Roller Kiln × × × ×
Glazed Wall Tile × × × ×
Glazed floor Tile × × × ×
Porcelain Tile × × × ×
Tableware     × ×
Magnetic Ceramics       ×
Sanitary Ceramics       ×
Hi-tech Ceramics
Specification Ø21-70mm,Length up to≤ 4500mm

2,

Dia.(mm) Length(mm) Dia.(mm) Length(mm)
Φ65 4190-4380 Φ45 3790-3980
3990-4180 3590-3780
3790-3980 3290-3580
3590-3780 2990-3280
3390-3580 2690-2980
3190-3380 2490-2680
2690-3180 ≤2480
≤2680 Φ42 3290-3580
Φ60 4190-4380 2990-3280
3990-4180 2690-2980
3790-3980 2490-2680
3590-3780 ≤2480
3390-3580 Φ40 2890-3180
3190-3380 2590-2880
2690-3180 2490-2580
≤2680 ≤2480
Φ55 4190-4380 Φ35     Φ33.7     Φ32 2890-3180
3990-4180 2590-2880
3790-3980 2490-2580
3590-3780 ≤2480
3390-3580 Φ30      Φ27 3090-3380
3190-3380 2790-3080
2690-3180 2490-2780
≤2680 ≤2480
Φ50 4190-4380 Φ25         Φ21 2790-3080
3990-4180 2490-2780
3790-3980 2290-2480
3590-3780 ≤2280
3390-3580 Other size according the request of customers'.
3190-3380
2690-3180
≤2680

 industrial Alumina Ceramic Boat

Packaging & Shipping



ceramic boat

Packaging Detail Packing:Carton or according to customer requirments
Delivery Detail:

Within 30 days after receipt deposit
OEM Service

1.OEM or can custom as per customer

2. For customers with good credit, We presented a small gift with Chinese characteristics.

3. We offer a warm and thoughtful service.

Company Introduction

Fame Rise Ceramics Ltd is a professional company in advanced ceramic industries. We offer high quality and high precision ceramic components for clients from worldwide. Our ceramic products are widely used in various fields of automotive, metallurgy, machinery, electronic & electrical, food, chemical, medical and so on. Our main products:

- Alumina Oxide ( 95% 96% 99% 99.5% 99.7% Al2O3 )
- Zirconia Oxide ( Yttria stabilized ZrO2 )
- Silicon Nitride ( Gas pressure sintered & Hot pressed Si3N4 )
- Boron Carbide ( B4C )
- Boron Nitride ( Hot pressed BN )
- Silicon Carbide(SIC, RBSIC, RESIC)

We focus on building long term cooperation relationship with our clients. For now, our products have been exported to North America, East Europe, West Europe, East Asia, Southeast Asia and get good reputation from our clients.

FAQ

Samples for ceramic boat


1. Would you please send us some samples?

Reply: Our company can provide  samples. However, the frieght should be born by the clients.

2. What's the color of your products?

 Reply: Different samples are featuring with different colors.

3.We are interested in your products, please give the details to me.

 Reply: Thank you for your letter. We will send you details information after you confirmed within 24 hours. If need, free samples will be sent.

4.What's your advantage?

(1)Many years professional production experience in this area.

(2)Strong production capacity.

(3) Professional senior engineer develop the best solution.

(4) Strict quality control system, CE, ISO9001 certificate available.

(5)Timely delivery, one hour to Qingdao port

(6)Professional after-sale service, Email will be get back in 24 hours.

(7)Product can custom as per customer requirments.
