Quansheng Big Power Handheld Walkie Talkie TG-1690

Quansheng Big Power Handheld Walkie Talkie TG-1690 thumbnail-1
Quansheng Big Power Handheld Walkie Talkie TG-1690 photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
QuanSheng Big Long Distance 10W Walkie Talkies
Model Number:
TG-1690
Contact Supplier Request Quote Chat Now
Fujian Nanan Quansheng Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen / shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name QuanSheng Big Long Distance 10W Walkie Talkies
Model Number TG-1690
Type Handheld
Dimensions 127*63*42mm
Frequency Range 400-480MHz
Storage Channel 16
Talk Range 10km

Quansheng Big power handheld walkie talkie TG-1690

This 10 Watts high power QuanSheng TG-1690 is QuanSheng's new arrival item.

10KM long range and with 4000mAh Polymer Li-ion Battery.



01. Outpower: 10W

02. Adopting newest polymer Li-ion battery

03. Adopting imported PC material in case to make it solid abradable

04. 350 hours' super-long waiting time

05. CTCSS/DCS

06. Voice prompt ( Chinese and English )

07. High or Low power adjust

08. Squelch level adjust

09. Wide/Narrow bandwidth

10. Jacklight

11. PC programmable

12. Channel scan

13. Time-out-timer

14. Low power alarm

15. DTMF PTT-ID

16. 1750Hz call tone

17. Tail tone Elimination

18. Roger





GENERAL

Frequency Range                                         UHF: 400-480MHz

                                                                        VHF: 136-174MHz

Channel                                                         16

Channel Spacing                                          25 /12.5KHz

Operating Voltage                                        7.2V

Antenna Impedance                                     50Ω

Operating Temperature                              -25°C~+65°C

Frequency Stability                                     ±2.5ppm

Battery                                                          4000mAh (Polymer Li-ion)

Dimensions                                                  127 X 63X 42mm

Weight                                                          295g



Transmitter

Output Power                                               10W

Modulation                                                   16KΦF3E/11KΦF3E

Maximum Deviation                                     ≤5.0KHz (W)

Spurious Emission                                       ≤65dB

Audio Distortion                                           ≤5%



Receiver

Sensitivity                                                     ≤0.25/0.28μV

Adjacent Channel Selectivity                     70/50dB

Intermodulation                                           60dB

Spurious Response Rejection                   70dB

S/N                                                                 43/38dB

Rated Audio Power Output                        ≤0.5W

Rated Audio Distortion                               ≤5%





Quansheng Big power handheld walkie talkie TG-1690





QuanSheng Electronics

 is one of the lead manufacturer of handheld radios

Top ten famous handheld radio brand in China

Design & manufacture 2 way radio for 20 years,

With ISO, CE, FCC and Rohs,

Taking 30,000 square meters,

with 500 people, 7 product line, and 9 SMT lines.

Export 1,000,000 pcs two way radios to 60 countries each year.
