| Model No. | RS-7512SH-12180D | |
| Rated voltage | 98VAC FULL WAVE RECTIFYING | |
| No Load | Speed(r/min) | 6480 |
| Current(A) | 0.085 | |
| At Max Efficiency | Speed(r/min) | 5005 |
| Current(A) | 0.29 | |
| Torque(mNm) | 43.92 | |
| Output(W) | 23.01 | |
| Eff.(%) | 63.48 | |
| At stall | Current(A) | 1 |
| Torque(mNm) | 2000 | |
*: AC full wave rectifying power supply
Unit Conversion: 1g.cm≈0.098mN.m≈0.014oz.in 1mm=0.039in 1g=0.035oz
Motor Design |
Customized Options |
|
. 2-pole stator . Sr ferrite permanent magnet . 3, 5, 7, 8, 9, 12,16 slots armature . Silicon-steel lamination with epoxy coating . High-carbon steel shaft . Cu-Ag alloy commutator . Copper-graphite brushes . Be-Cu leaf-brush commutating system . SECD round / flat type housing . SECD end cap / glassfiber reinforced PA6/6 end cap . Cylinder / self-aligning Cu-Fe alloy sintered bushes . 155℃(class F) magnet wire
|
. Leadwires with connector / pins . EMI suppression components . PTC or thermostate protection . Built-in AC/DC rectifier . Built-in cooling fan . Multiple output shaft . nurls, straight knurls, D-cut, stepshaft . Shaft-mounted gears, eccentric gears, belt pulleys . Stainless steel (SS304, SS420) shaft . Ball bearing . Cage-brush commutating system . Precious metal brush / commutator . Hall encoder . Low-cogging torque design . 180℃ (class H), 200℃ (class C) magnet wire . -40℃ ~ 220℃ bearing lubricant . Neodymium magnets |
