Mini Pocket-size Design Two Way Radio TG-K100

Mini Pocket-size Design Two Way Radio TG-K100 thumbnail-1
Mini Pocket-size Design Two Way Radio TG-K100 photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
QuanSheng walkie talkie
Model Number:
TG-K100 walkie talkie
Contact Supplier Request Quote Chat Now
Fujian Nanan Quansheng Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen / shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name QuanSheng walkie talkie
Model Number TG-K100 walkie talkie
Type Handheld
Dimensions 110*56*37cm
Frequency Range 136-174MHz/400-480MHz/245-246Mhz
Storage Channel 16 walkie talkie
Talk Range 4-6km

mini pocket-size design two way radio with DTMF PTT-ID TG-K100    2015 new walkie talkie

  mini pocket-size design two way radio mini pocket-size design two way radio mini pocket-size design two way radio

walkie talkie

1. Available in 3 beautiful colors

2. Jacklight

3. PC programmable

4. Channel scan

5. TOT

6. Low power alarm

7. Wide/Narrow bandwidth

8. Squelch level adjustable

9. H/L output power selective

10. Voice prompt

11. CTCSS/DCS

12. Dual-watch operation

13. PTT-ID

14. DTMF function

15. 1750Hz call tone

    walkie talkie

walkie talkie

General

Frequency Range                                                      VHF: 136-174MHz

                                                                                     UHF: 400-480MHz

Channel                                                                      16

Channel Spacing                                                       25 /12.5KHz

Operating Voltage                                                     3.6 7.2V

Antenna Impedance                                                  50Ω

Operating Temperature                                           -25°C~+65°C

Frequency Stability                                                   ±2.5ppm

Battery                                                                        1500mAh (Li-ion)

Dimensions (H*W*D)                                                  103 X 61X 30mm

Weight                                                                         164g



Transmitter

Output Power                                                              ≤5W

Modulation                                                                  16KΦF3E/11KΦF3E

Maximum Deviation                                                    ≤5.0KHz(W)

Spurious Emission                                                      ≤65dB

Audio Distortion                                                          ≤5%



Receiver

Sensitivity                                                                      ≤0.25/0.28μV

Adjacent Channel Selectivity                                      70/50dB

Intermodulation                                                            60dB

Spurious Response Rejection                                    70dB

S/N                                                                                  43/38dB

Rated Audio Power Output                                          ≤0.5W

Rated Audio Distortion                                                 ≤5%

walkie talkie



mini pocket-size design two way radio TG-K100mini pocket-size design two way radio TG-K100mini pocket-size design two way radio TG-K100mini pocket-size design two way radio TG-K100




  walkie talkie



QuanSheng is one of the lead manufacturer of handheld radios walkie talkie

Design & manufacture 2 way radio walkie talkie for 20 years,

With ISO, CE, FCC and Rohs,

Taking 30,000 square meters,

with 500 people, 7 product line, and 9 SMT lines.

Export 1,000,000 pcs radios to 60 countries each year.



Welcome and thank you for visiting our website.

Please send us inquiry or SMS us on Trade Manager.

It is our honor to help you.

We promise to response in 24 hour.
