DIN Abrasion Testing Machine for Flexible Materials
Abrasion Testing Machine
The main function of Rotating Cylindrical Drum Device is to test the friction of surface by a particular piece
of sandpaper, After friction for a certain time, and then assess the condition of material surface weight, volume
and thickness, from this standard to assess the abrasive nature of materials. .
Main functions:
This Rotating Cylindrical Drum Device is a high efficiency, good reproducibility and easy to operate, applied to
test the abrasive nature of material, as such elastic material, rubber, tires, convey belt, transmit belt, sole,
synthetic leather, leather and others
Corresponding standard :
GB/T9867,GB/T 20991,GB/T 26703,EN ISO 20344,ISO 4649,DIN 53516,BS 903:A9,SATRA TM147
Applicable industry:
Applied to test leather performance in shoes, clothing, luggage handbag industry, research laboratories,
commodity inspection, arbitration and technical supervision departments .
Technical parameters :
dler |
150mm |
abrasion stroke |
40 ± 0.2M |
stroke |
20m/40m presetting |
grips lateral displacement |
4.2 ± 0.04rpm |
Idler wheel speed |
40 ± 1cpm |
Measuring way |
Auto/Manual presetting |
load |
2.5 ± 0.1N,5 ± 0.1N,10 ± 0.1N |
sand paper |
60 germany |
Dimension |
95*66*31cm |
model |
HY-766 Rotating Cylindrical Drum Device |
Abrasion Testing Machine
1. What about your delivery time?
A: We have skilled workers and professional work division for assembly and checkout. Usually, our delivery
time is 7~14days.
2. What about the transportation?
A: We have stable forwarding agent for Air transportation and Sea transportation. And also express delivery
of TNT, DHL.
3. What about your packaging?
A: Digital material universal testing machine packed with export standard wooden box.
Abrasion Testing Machine
After-sales service commitment
Warranty
The testing machine is guaranteed for a year by Jinan Kason Testing Co., LTD and has whole-life service
(including machinery, clamps, hardware, software).
Training
1. We will provide you the operation video about how to install and operate the equipment. We also sincerely
welcome every customer to visit and learn the equipment operation.
2. We can arrange engineer to train the operation of equipment to customer’s company when you need.
Maintenance services
Consultation services. We answer your question timely via the telephone or email.
Our exquisite technology, excellent quality, competitive price, good service and you give us the concern and
support, there will be enjoyable and long-term friendly cooperation.
Abrasion Testing Machine
Factory
Our CE Certificate
Abrasion Testing Machine
