HS-100H Portable Ultrasonic Flowmeter/Digital Ultrasonic Flowmeter
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HS or OEM
Model Number:
HS-100H
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HS-100H Handheld Ultrasonic Flowmeter/Digital Ultrasonic FlowmeterNegotiableMOQ: 1 Set -
Digital Display Package Box Drop Testing Machine/Drop TesterUS$ 1,000 - 4,000MOQ: 1 Set
-
YDW-10 Cement Mortar Flexure Testing Machine/Flexural TesterUS$ 1,000 - 5,000MOQ: 1 Set
-
ALR Series Manual Hydraulic Test Stand, Hydraulic Test BenchUS$ 500 - 5,000MOQ: 1 Set
-
KJZ-500 Electric Cement Mortar Flexure Testing Machine,Flexual Testing EquipemntUS$ 400 - 700MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
HS or OEM
Model Number
HS-100H
Specifications
Ultrasonic FlowmterApplicable for steel, stainless steel, cast steel, PVC, FRP and other uniform dense quality pipe
HS-100H handheld ultrasonic flowmeter
HS-100H handheld ultrasonic flowmeter for various industrial field in the liquid flow-line measurement of calibration
and inspection. Has high accuracy, consistency is good, battery-powered, simple operation and easy to carry and
and inspection. Has high accuracy, consistency is good, battery-powered, simple operation and easy to carry and
other features, is currently the smallest, lightest quality, truly portable ultrasonic flowmeter, the products have been
exported to Japan, South Korea, Southeast Asia, Australia, the United States and other regions, has been widely praised.
Product Specifications:
Pipe Size: 15mm-6000mm
Transducers: Model M1 for standard, other 3 models for optional
Transducer Cord Length
Standard 2x10 meters, optional 2x 500 meters
Size: Small size 220* 92* 32mm
Weight: Light weight 538g with batteries
ultrasonic flowmeter optional sensors:
1. Standard Small stent sensors(DN15-100mm)
Fluid temperature: <110 Degrees
Dimension: 200 * 25 *25mm
Handle Length: 100mm
2. Standard midsize stent sensors(DN50-DN700mm) (Magnetic)
Fluid temperature: <110 Degrees
Dimension: 280 *40*40mm (2)
3. Standard midsize sensors M1(DN50-DN700mm) (Magnetic)
Fluid temperature: <110 Degrees
Dimensions: 60*45 *45mm
4. Standard large size sensors L1(DN300 bove)
Fluid temperature: <110 Degrees
Dimensions: 80 *70*55mm
Product Specifications:
Pipe Size: 15mm-6000mm
Transducers: Model M1 for standard, other 3 models for optional
Transducer Cord Length
Standard 2x10 meters, optional 2x 500 meters
Size: Small size 220* 92* 32mm
Weight: Light weight 538g with batteries
ultrasonic flowmeter optional sensors:
1. Standard Small stent sensors(DN15-100mm)
Fluid temperature: <110 Degrees
Dimension: 200 * 25 *25mm
Handle Length: 100mm
2. Standard midsize stent sensors(DN50-DN700mm) (Magnetic)
Fluid temperature: <110 Degrees
Dimension: 280 *40*40mm (2)
3. Standard midsize sensors M1(DN50-DN700mm) (Magnetic)
Fluid temperature: <110 Degrees
Dimensions: 60*45 *45mm
4. Standard large size sensors L1(DN300 bove)
Fluid temperature: <110 Degrees
Dimensions: 80 *70*55mm
Main Specs:
| Item | Handheld ultrasonic flowmeter |
| Linearity | 0.5% |
| Accuracy | ± 1% first to meet the accuracy in domestic |
| Repeatability | 0.2% |
| Response Time | 0-999 seconds, user-configurable |
| Velocity | 0.01± 32m/s |
| Pipe Size | 15mm-6000mm |
| Security | Setup values Modification Lockout. Access code needs unlocking |
| Display | 4 lines English characters on-screen display instantaneous flow, velocity, , cumulative flow, |
| Transducers | Model M1 for standard, other 3 models for optional |
| Transducer Cord Length | Standard 2x10 meters, optional 2x 500 meters |
| Power Supply |
3 AAA Ni-H built-in batteries. When fully recharged it will last over 10 hours of operation. 100V-240VAC for the charger |
| Housing Material | ABS |
| Size | Small size 220× 92× 32mm |
| Weight | Light weight 538g with batteries |
Product Features:
| Applicable to | Applicable for steel, stainless steel, cast steel, PVC, FRP and other uniform dense quality pipe |
| Liquid types | water, sea water, sewage, alcohol, various oils such as uniform, single, stable liquid |
| Output Signal |
OCT output of positive and negative, the net cumulative pulse signal and frequency signal (1-9999Hz optional) |
| Data Interface |
RS232 interface is used for net testing or export the record data. RS-232C, baud-rate: from 75
to 57600. Protocol made by the manufacturer and compatible with that of the FUJI ultrasonic
flow meter. User protocols can be made on enquiry. |
| Straight pipe length | Upstream> 10D, Downstream> 5D, Length from pump exit> 30D |
| Data Logger | Built-in data logger can store over 2000 lines of data |
