Specifications
Automated calibration,Automated gainDAC,AVG,TCG,B scan,AWS
High-speed capture and very low noise
Ultrasonic Flaw Detector
HST500 Ultrasonic Flaw Detector
Performance Features
l Automated calibration of transducer Zero Offset and/or Velocity ;
l Automated gain,Peak Hold and Peak Memory;
l Automated display precise flaw location(Depth d,level p,distance s,amplitude,sz dB,Φ);
l Automated switch three staff gauge (Depth d,level p,distance s);
l 100 independence setup, any criterion can be input freely, we can work in the scene without test block;
l Big memory of 300 A graph.
l Gate and DAC alarm;Acoustic-Optical alarm;
l RS232/USB port,communication with pc is easy;
l The embeded software can be online updated;
l Li battery, continue working time up to 10 hours;
l Display freeze;
l Automated echo degree;
l Angles and K-value;
l Lock and unlock function of system parameters;
l Electronic clock calendar ;
l Two gates setting and alarm indication;
l High-speed capture and very low noise;
l DAC,AVG ; Solid metal housing;
l Automated calculate the size of the flaw with w ide bottom type in AVG function.
l AWS D1.1;
l 6dB DAC functions;
l Provides high contrast viewing of the waveform from bright, direct sunlight to completae darkness and easy to read from all angles;
l Powerful pc software and reports can be export to excel;
Measuring Range and Measuring Error
Range of scanning: 0 mm ~6000 mm
Resolution for scanning: 0.1mm (2.5mm ~100mm) 1mm (100 mm ~6000mm)
Range of gain: 0dB ~110 dB
D-Delay: -20µs~+3400µs
P-Delay: 0µs~99.99µs
Sound speed: 1000 m/s~15000m/s
Operation Environment
Temperature:-10°C~50°C
Humidity:20%~90%RH
Free of strong magnetic field and corrosion.
Power supply
Li battery7.4V 4800mAh
Overall Dimension and Weight
Overall dimension: 240mm×150mm×50mm
Weight: 1.6kg
