HST650 Ultrasonic Flaw Testing Equipment
♦Automated calibration,Automated gain
♦DAC,AVG,TCG,B scan,AWS
♦High-speed capture and very low noise
♦high contrast viewing of the waveform from bright
♦Powerful pc software and reports can be export to excel
Features
- Automated display precise flaw location(Depth d,level p,distance s,amplitude,sz dB,Φ);
- Automated switch three staff gauge ((Depth d,level p,distance s);
- Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity ;
- Convenient to make and use DACTCG and AVG to evaluate the echo, the curve can be modified and compensated
- 6dB DAC functions;
- Standards of test for DAC is saved.
- 500 independence setup, any criterion can be input freely, we can work in the scene without test block;
- Big memory of 1000 A graph
- Automated gain and gain scan;
- Peak Hold and Peak Memory;
- B scan;
- AWS D1.1
- Automated make video of test process and play; use upan,the length of video is unlimited.
- Powerful pc software and reports can be export to excel;
- Li battery, continue working time up to 10 hours;
- The embeded software can be online updated;
Other assistant function
- Display freeze;
- Automated echo degree;
- Angles and K-value;
- Lock and unlock function of system parameters;
- Electronic clock calendar ;
- Two gates setting and alarm indication;
- Gate and DAC alarm;
Specifications
Title |
Parameter |
Title |
Parameter |
Measuring Range(mm) |
0 ~ 10000 |
Measurement Mode |
Single,Dual,Thru |
Vertical Linearity Error |
≤3% |
Reject |
0~80% |
Horizontal Linearity Error |
≤0.1% |
Pulse Displacement(μs) |
-20 ~ +3400 |
Sensitivity Leavings |
≥62dB |
Zero(μs) |
0.0 ~ 99.99 |
Dynamic range |
≥34dB |
Port Type |
BNC(Q9) |
Resolving Power |
≥36dB |
Operating Temperature (°C) |
-20~50 |
Frequency Range(MHz) |
0.5 ~ 20 |
HxWxD(mm) |
240x156x50 |
Gain(dB) |
0 ~ 120 |
Weight(kg) |
1.0(with battery) |
Material Velocity(m/s) |
1000 ~ 15000 |
HST650 Ultrasonic Flaw Detector/metal flaw detector
