JBW- 750 Automatic Computer Charpy Impact Testing Machine
1. Application
JBW series Computer charpy impact test machine are mainly used to
determine the antiimpact capability of metal materials under dynamic load. Carry out the functions of zero clearing and automatic return, capturing the value of lost impact energy and pendulum cycle by means of setting up with computer program, and the results can be monitored, stored and printed out.
Control box or computer program control is alternative operating method. JBW series impact testers are adopted by many institutes and high-tech enterprises.
2. Standards: charpy impact test machine
ASTM E23, ISO148-2006 and GB/T3038-2002, GB/229-2007.
Contact: Alice Zhang Skype: hssdtest What's APP / TEL: +86-15098778967
3. Features: charpy impact test machine
3.1 Fully automatic, sample feeding, auto position the sample; high efficiency;
3.2 Pendulum rising, impact, sample feeding, position, free releasing is realized automatically by easy PC mouse click;
3.3 Safety pin guaranties the impact action, standard protection shell to avoid any accident.
3.4 Pendulum will automatically rising and ready for next impact action after specimen breakout.
3.5With two pendulums (big and small), PC software to display the energy loss, impact tenacity, rising angle, test average value etc. test data and result, also the curve display available; with calculation and report printing function. The dial scale can show test results too.
4. Main Technical Specifications: charpy impact test machine
Model |
JBW-300Z |
JBW-500Z |
JBW-800Z |
|
display |
computer control automatic |
|||
impact energy |
150/300J |
250/500J |
500/800J |
|
|
The distance between the pendulum shaft and impact point |
750mm |
800mm |
||
Impact speed |
5.2m/s |
5.4 m/s |
5.9m/s |
|
Pre-rising angle of the pendulum |
150° |
|||
Specimen bearer span |
40+0.2mm |
|||
Round angle of the jaw |
R1-1.5mm |
|||
Round angle of impact edge |
R2-2.5mm,R8±0.05mm |
|||
Angle accuracy |
0.1° |
|||
Standard specimen dimension |
10mm×10mm×55mm |
|||
Sample box capacity |
10 pcs |
|||
Power supply |
3phs, 380V, 50Hz Or 220V,60Hz |
|||
Dimensions (mm) |
2124 x 600 x 1340 |
2200 ×650 ×1960 |
2450 x 1200 x 2455 |
|
Net Weight (kg) |
450 |
650 |
2300 |
|
charpy impact test machine
VU-2Y DWC-40/60/100 DWC-196 CST-50
1.Shipping & delivery: It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.
2. Machine' Packaging: Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver? charpy impact test machine
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?charpy impact test machine
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users.
♥ More information welcome to contact us now!
And welcome to our company! We display more new design in our showroom.
♥ Main web site: : http://www.
Tel: 86 531-58618759| Fax: 86 531 86113759
