ALT552H Caron Batch Coding Machine/Printing Machine of CYCJET

Print Height

0.8-108mm

Print Spacing

8mm-10mm,it is subject to the printing content & ink type

Print Lines

The lines unlimited within Max height 54mm.

Print Length

Single file max length 20000 dots (the Max height 2.54m when the resolution is 200DPI)

Print Speed

60m/min (Cross direction resolution 100DPI)

Print Resolution

Resolution height is 200DPI; Cross direction resolution 100-400DPI can be adjustment

Print Fonts

The built-in various font, and horizontal bar,vertical bar,dot-matrix,bold font can be free change.

Print Content

Real Date, Real time, Photo, Letter, Shift group, Serial number, Batch number, Lot number Barcode and 2D code can be free print.

Print Direction

Upward printing, downward printing, side printing(360°direction printing)

Font library

Standard font library are Chinese & English, and The Spanish,Portuguese,Arabic font library can be optional

Operator Interfaces

Image-style & Chinese or English ( Spanish,Portuguese,Arabic)menu, What you see is what you get.

Memory Function

More than 1000pcs text can be storage

Display

3.5inch color touch screen

Ink Type

Ink is originally from UK. There are Solvent-based ink (machine should be regular maintenance); Invisible ink (Machine should be regular maintenance); Oil-based ink (machine maintenance free).

It can be print on the surface of plastic,glass,metal,paper,wood...

Ink Color

Black, Red,Yellow, Blue,Green,white, etc…

Each Ink Cartridge

Each ink cartridge can be print 1.15 billion ink dots, when efficient production:

*86,800,000.00pcs 7×5 Micro point fonts or 21,700,000.00 pcs7×5standard dot-matrix font(theoretical value)

*each ink cartridge can be print 500,000.00 to 1 million pcs bottle cover or medicine box with 2 lines or three lines, the using cost for each product is RMB0.001Yuan);

*each ink cartridge can be print 50,000.00 to 100,000.00pcs big carton with one line or two lines big dot-matrix font, , the using cost for each carton is RMB0.01Yuan);

Protection level

Not suitable for high dust, high humidity working environment

Weight of Machine Dimension of Machine

2KG
148*150*115mm

Powder

AC220V±10%, 50-60HZ, 5 W;

Humidity Range
Temperature Range

10-90% Non-condensing
5-40°C
