High Temperature Creep Tensile Testing Machine

US$ 1,000 - 10,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

HST

Model Number:

WDW-G

Contact Supplier Request Quote Chat Now

Jinan Hensgrand Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name HST

Model Number WDW-G

Power Electronic

Usage Tensile Testing Machine

Specifications

High Temperature Tensile Testing Machine
1. Configurated with high low temperature box
2. Computer auto control

WDW-G Material High Temperature Universal Tensile Testing Machine

1. Application:

WDW series computerized electronic universal testing machines are designed and manufactured according to

ASTM, ISO, DIN, GB and other international standards. Applicable for wide range of material for tension, compression,

bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is

widely used in the corresponding industries, research and development, test institutes and training centers etc.

Configurated with high, low temperature box is able to finish temperature environment test.

2. Main Specifications:

Model	WDW-5	WDW-10	WDW-20		WDW-30	WDW-50		WDW-100
Max. Load	5kN 500kgf 1120lbf	10kN 1000kgf 2240lbf	20kN 2000kgf 4480lbf		30kN 3000kgf 6720lbf	50kN 5000kgf 11200lbf		100kN 10000kgf 22400lbf
Load accuracy	≤±1%
Load range	2%-100% of full scale
Load resolution	1/200000 of full scale
Disp. resolution	0.01mm
Test speed	0.05-500mm/min						0.05-300mm/min
Tensile space	750mm\|30in			650mm\|25.6in			650mm\|25.6in
Comp. space	750mm\|30in			650mm\|25.6in			650mm\|25.6in
Test width	375mm			400mm			420mm
Temperature range	50°C~300°C
Thermostat specifications	High precision temperature control meter, multilevel PID adjust, interval 1°C, accuracy: 0.5°C
Temperature fluctuation	±1°C
Temperature gradient	Better than 3°C
Heating up time	Room temperature to 300°C, less than 50 minutes
Uniform temperature zone length	More than 150mm
Size of oven body	Hearth: depth 650mm×width 240mm×height400mm Overall size:1000mm×390mm×600mm
Material	Stainless steel inner shell, long durability, good anti-corrosion performance
Structure	Large observation window, easy operation, with guide rail
High temperature box power	2kW/AC380V/50Hz
Dimension	730×430×1700mm			755×480×1780mm			825×600×1950mm
Power supply	220V, 1ph, 0.5kW			220V, 1ph, 0.75kW			220V, 1ph, 1kW
Weight (kg)	250kg\|550lb			280kg\|616lb			350kg\|770lb

3. Feature:

3.1 Main Unit:

This machine adopt double space structure, the upper space used for tensile test, the lower spaceused for compression and bending test. The beam moving speed is stepless adjust. The drive system consist of servo control reduction motor, arc synchronous belt, ball screw, moving steadily, high working efficiency, low noise, no pollution.

3.2 Electrical measurement and control system

3.2.1 With protect function of overload,over current, over voltage, displacement limit, emergency stop, etc .

3.2.2 The controller can control more load sensor, high integration, stable and reliable, easy to adjust.

3.2.3 When finished testing, automatic stop.

3.2.4 Control system with programmable amplifier A/D conversion, digital I/O, counting and pulse happen (PWM), and other functions in one

3.2.5 Mechanical zero setting, automatic force measurement, zero setting, calibration and save, highly integrated control circuit

3.3 Software and software interface

3.3.1 Based on Windows operation platform, the software adopting modulus design, with simple operation and powerful functions

3.2.2 The control panel has defined all the control parameters, data dealing method and report content and form, different test can be set according to the control panel.

3.2.3 Program adopting open database structure, integrated the GB, ISO,ASTM,JIN, DIN testing methods and can customized according to special requirements

3.2.4 With internet interface, can transmit, save and print data. Can connect enterprise Internal LAN and Internet.

3.2.5 Can edit and set the report form freely, also can print the testing data

High Temperature Tensile Testing Machine:
