Specifications
1.usage:Leeb hardness test2. high testing accuracy
4. with micro printer
5. Large LCD display
HLN-160 Portable Hardness Tester
Application:
Hardness measurement of products for mass producing
Site hardness test for machinery after installation or permanent assembly parts.
Hardness measurement of heavy parts.
Hardness measurement of the mould cavity.
Hardness measurement of small space machinery.
Failure analysis of equipment.
Distinguishing metal materials in stock.
Hardness controlling test for the heat treatment of anneal,temper,quench,etc
Tech parameter
Testing range |
150-960)HLD (17-68.5)HRC (19-651)HB (80-976)HV (30-100)HS (59-85)HRA (13-100)HRB |
Testing degree |
360°C |
Testing material |
10 kinds |
Data store |
250 group (impact tiem 1~26) |
Software calibration range |
±15HLD |
Hardware calibration range |
±30HLD |
Working voltage |
3.3V |
Continuous working time |
40h |
Interface standards |
RS232 |
Size |
(160×80×42)mm |
Weight |
0.3kg |
Features:
1) has power-on self-checking function and factory parameter recovery function;
2) large-capacity storage, can store 250 groups of data;
3) Has peak holding circuit, can adapt to multiple impact devices;
4) Automatically convert to HRC, HRB, HRA, HB, HV and HS according to different impact devices;
5) Intelligent voltage management system ensures stable power supply;
6) Has RS232 port, can transmit data to the micro computer;
7) Alarm system; battery indicator, etc.
