HR-150A Rockwell Hardness Tester with cheap price
Contact me: jessica Skype:jessica-hssd
1.Application:
HR-150A Manual Metal Rockwell Hardness Tester is an indispensable hardness measuring instrument in machinery, metallurgy and metrology department.
It mainly functions are as follows:
1.1. Lever Loading, manual operation, durable and reliable.
1.2. No friction spindle, high precision test force.
1.3. Precision hydraulic buffers, steady load.
1.4. Dial display the hardness value, HRA, HRB, HRC, and can choose other Rockwell Scale.
1.5. Accuracy according to GB / T230.2, ISO 6508-2 and American ASTM E18 standard.
2.Usage Range:
Rockwell hardness measurement of ferrous metals, non-ferrous metals and non-metallic materials.
Wide range of applications, suitable for rockwell hardness testing of hardening, quenching and other heat-treated material.
3.Specifications:
Model |
HR-150A |
Preliminary Test Force |
98 N, 29.40N |
Total Test Force |
588.4N, 980.7N, 1471N (60, 100, 150kgf) |
Test Range |
(20-88)HRA; (20-100)HRB; (20-70)HRC. |
Max. Test Height |
170mm |
|
The Distance Between Pressure Head Center And The Wall |
135mm |
Hardness Resolution |
0.5HR |
Dimensions |
466*238*630mm |
Weight |
70 KG |
4.Standard Accessories:
Large Flat Anvil: 1 PC.
Small Flat Anvil: 1 PC.
Large V-notch Anvil: 1 PC.
Diamond Cone Penetrator: 1 PC.
1/16" Steel Ball Penetrator: 1 PC.
Rockwell Standardized Block: 5 PCS.
Lifelong after-sales service & maintenance;
24 hours’ consult pre-sale on line or by Phone
Overseas training, installation is avaliable.
