Specifications
portable laser marking machine with low price:1.low dissipation
2.good stability
3. not affected by external dust gas
Portable Laser Machine with Low Price
1. 100000 hours of free maintenance.
2. Processing speed is 2 to 3 times the traditional laser marking machine.
3. Wind cooling fiber laser, no consumables, low maintenance, high photoelectric conversion rate, low consumption (800 w) or less, use cost.
4. Integrated design, small size (there are a whole cabinet and portable optional).
5. Environmental adaptation ability strong can be in vibration, shock, dust, humidity environment continuous work, easy to implement with optical fiber coupling, which can realize remote work.
Bar code, qr code, graphics, text rules and irregular marking serial number, etc.
6. Software running on WINDOWS platform, Chinese/English interface, can be compatible with AUTOCAD, CORELDRAW, PHOTOSHOP software, such as PLT, PCW, DXF, BMP, etc, but also can be used directly SHX, ttf font.
7. Application Scope:
Suitable for electronic components, electrical products, IT industry, auto parts, hardware tools products, precision instruments, gift accessories, medical equipment and other high-end products of precision, fine logo printing. Typical applications such as, plastic (PA66) insulation flying laser marking, metal plate laser marking, packing box body online laser marking, etc.
Technical Parameter:
Laser type |
Fiber |
Output Power |
20W |
Beam quality M2 |
<2 |
Laser wavelength |
1064 nm |
Pulse frequency |
20 KHZ - 100 KHZ |
Marking range |
110 mm x 110 mm (can be customized) |
MarkingSpeed |
7000mm/s |
Marking Depth |
≤0.3mm |
Marking Line Width |
0.01-0.2mm (based on difference material) |
Min character Size |
0.015mm |
Repeat accuracy |
± 0.003 mm |
Marking area locating |
Red-light locating system |
Power supply |
AC 100-260 v 50/60 hz |
Power |
≤800W |
