GBS-60 Digital Display Erichsen Cupping Testing Machine
1.Application & Features:
The cupping testing machine is used to test extend and stretch capacity of metal thin plate and band.
It is the only instrument to test the metal’s plastic deformation.Also it can be used to test non-ferrous
metals anisotropic character if adding impact cup mould.
The machine adopts high precision raster measure instrument to test Erichsen value so it has a high
testing precision. It adopts the electric control machinery onload and LCD spoke sensor so it raised the
testing precision of the main test force and accuracy of controlling sample breaking.
2.Standards:
ISO20482: 2003 Metallic materials-Sheet and strip-Erichsen Cupping Test,
GB/T4156-2007 Metallic materials-Sheet and strip-Erichsen Cupping Test.
3.Feature:
1.Use a servo motor to load instead of hydraulic piston and cylinder.
2.Change oil pressure cylinder to load cell, more precision and reliable.
3.Auto stop when crack appears, convenient to observe the crack.
4.With peak value memory function,like max. punch load,max. deformation deep etc.
5.Turnover grips,punch and sample is easy to change.
4.Specification:
Model |
GBS-60 |
Display Mode |
LCD Display |
Specimen Thickness |
0.1-2 mm |
Specimen Width |
100 mm |
Punch Max. Stroke |
40 mm |
Clamping Piston Stroke |
40 mm |
Max. Punching Load |
60 KN |
Max. Clamping Load |
25 KN |
Standard Punch Diameter |
Φ20±0.05 mm |
Standard Cushion Mold Hole Diameter |
Φ33±0.1 mm |
Standard Press Mold Hole Diameter |
Φ27±0.05 mm |
Display Resolution |
0.01 mm |
Speed |
2-100 mm/min |
Weight |
500 KG |
5.The Packing Way Of Our Export Machines:
6.The Realistic Pictures Of Our Factory:
7.Our CE Certificate:
8.Our company can also produce the customized testing machines as clients' requirements.
Best service and the best price for you.
You can contact me in any time as the below information.
