GG-65 Steel Tube Bending Testing Machine Price

US$ 15,000 - 16,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

HST

Model Number:

GG-65

Jinan Hensgrand Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name HST

Model Number GG-65

Power Electronic

Usage Bending Testing Machine

Specifications

1.Steel Tube Bending Testing Machine Price
2.Digital Display
3.CE Certificate
4.Forward Bending Angle:0-120 Degrees At Will

Product Description

Jinan Hensgrand Instrument Co., Ltd has the self-management import and export right.

All of our testing machines through the EU CE Certificate.

GG-65 Steel Tube Bending Testing Machine Price

1.Application:

This machine is suitable for cold bend test of the steel tube.The main technical

parameters accord with GB/T244-2008 <Metallic materials-Tube - Bend test>,

GB/T30912008<Welded steel pipes for low pressure liquid delivery.

This machine is suitable for bend test of the metallic material rods and bars, the

plate,spiral steel, and widely applies in the building materials, the metallurgy,the

Scientific Research Unit, the universities, colleges and institutes, the quality

detection center and the commodity inspection department.It is indispensable

ideal testing machines to test the cold bending property of the steel tube.

2.Main Specifications:

Mode	GG-50		GG-65
Max Bending Diameter Of Steel Tube	50mm		60mm
Bending Angle	0° To 120°At Will
Rotating Speed Of Working Table	≤2.0r/min
Distance Between The Center Of Two Rolls	165mm	165mm
Diameter Of The Working Table	Φ760mm	Φ860mm
Motor Power	1.5 KW	2.2 KW
Standard Bending Accessory	Φ20, Φ40	Φ30, Φ50
Dimension (mm)	12009001188	170011701150
Weight (KG)	1500 KG	2500 KG
