400 nickel copper alloy steel pipe price N04400
Monel 400(UNS N04400/2.4360) is a nickel-copper alloy with high strength and excellent resistance to a range of media including seawater, dilute hydrofluoric and sulfuric acids, and alkalies.
Alloy 400 containing about 30–33% copper in a nickel matrix has many similar characteristics of commercially pure nickel, while improving upon many others. Addition of some iron significantly improves the resistance to cavitation and erosion in condenser tube applications. The main uses of alloy 400 are under conditions 2.4360 of high flow velocity and erosion as in propeller shafts, propellers, pump-impeller blades, casings, condenser tubes, and heat exchanger tubes. Corrosion rate in moving seawater is generally less than 0.025 mm/year. The alloy can pit in stagnant seawater, however, the rate of attack is considerably less than in commercially pure alloy 200. Due to its high nickel content (approx. 65%) 2.4360 the alloy is generally immune to chloride stress corrosion cracking. The general corrosion resistance of alloy 400 in nonoxidizing mineral acids is better compared to nickel. However, it suffers from the same weakness of exhibiting very poor corrosion resistance to oxidizing media such as nitric acid, ferric chloride, cupric chloride, wet chlorine, chromic acid, sulfur dioxide, or ammonia. In unaerated dilute hydrochloric and sulfuric acid solution the alloy has useful resistance up to concentrations of 15% at room temperature and up to 2% at somewhat higher temperature, not exceeding 50°C. Due to this specific characteristic, alloy 400 is also used in processes where chlorinated solvents may form hydrochloric acid due to hydrolysis, which would cause failure in standard stainless steel.
Typical applications are valve and pump parts, propeller shafts, marine fixtures and fasteners, electronic components, chemical processing equipment, gasoline and freshwater tanks, petroleum processing equipment, boiler feedwater heaters and other heat exchangers
Chemical Composition 2.4360 monel 400
| Grade | Ni% | Cu% | Fe% | C% | Mn% | C% | Mn% | Si% | S% |
|---|---|---|---|---|---|---|---|---|---|
| Monel 400 | Min 63 | 28-34 | Max 2.5 | Max 0.3 | Max 2.0 | Max 0.05 | Max 1.0 | Max 0.5 | Max 0.024 |
Specifications
| Grade | UNS | Werkstoff Nr. |
|---|---|---|
| Monel 400 | N04400 | 2.4360 |
Physical Properties 2.4360 monel 400 alloy
| Grade | Density | Melting Point |
|---|---|---|
| Monel 400 | 8.83 g/cm3 | 1300°C-1390°C |
Mechanical Properties alloy 400
| Alloy | Tensile Strength | Yield Strength | Elongation |
|---|---|---|---|
| Monel 400 | 480 N/mm² | 170 N/mm² | 35% |
Our Production Standard ASTM 2.4360
| Bar | Forging | Pipe | Sheet/Strip | Welding Wire | |
|---|---|---|---|---|---|
| Standard | ASTM B164 | ASTM B564 | ASTM B165 | ASTM B127 | ERNiCu-7ERNiCu-7 |
1. If we travel to China to checking your facility, are you welcome?
Of course, why not?
we will provide the whole accompany from you landing in China.
Only Give us a call before your arrive.
We will pick up you from the airport, living in our company's hotel, and driving by car take you visiting our company.
Warm Welcome!
2. How many sales person in your team?
present 8 sales, but more hands help in work, total team is 20+ workers.
So do not worry, not the one person company.
3. How Many Years of your company working in this industry?
We are 20+ years, from last century.
Expanding the market, and cultivate our techniques, two ways all in work together.
4. Could you show me some photos of your producing working?
here, following is our working plant, all is same when you come to China to audit.
we are locate in Shanghai. Building 32, No 518 XinZhuan Rd., Songjiang District, Shanghai, China
Postcode: 201601
Not matter where you come from, give us a call, we will pick up from the airport, station, etc.
Welcome take a visiting to our company!
Metro: Line 9, Jiu Ting Station
Train: HongQiao Station (22KM, take taxi 25 mins arriving at our company)
Bus: Shanghai Sourth Station (20KM, take taxi 20 mins arriving at our company)
Airplane:
From: PVG Airport (Shanghai Pudong Airport) only 50~53kilometer, by Taxi 50 mins arriving at our company,
From: Shanghai HongQiao Airport, 22KM, take 25 mins arriving at our company.
Standard export package with water proof paper, and metal pallet, and angle bar protection, and steel strip or as required
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
