excellent corrosion proof thermal stabilization hastelloy g-35 alloy n06035
Product details:
Hastelloy G-35 n06035
Equivalent designations
UNS n06035
DIN W. Nr. 2.4643
Form |
ASTM |
Rod |
B 574 |
Plate, sheet and strip |
B 575 |
Seamless pipe and tube |
B 622 |
Welded pipe |
B 619, B 775 |
Welded tube |
B 626, B 751 |
Welding fitting |
B 366 |
Forged or rolled pipe flange and forged fitting |
B 462 |
Billet and bar for reforging |
B 472 |
Forging |
B 564 |
Chemical composition of n06035
% |
Ni |
Cr |
Mo |
Fe |
Co |
W |
C |
Mn |
Si |
P |
S |
Al |
Cu |
V |
min |
balance |
32.25 |
7.6 |
|
|
|
|
|
|
|
|
|
|
|
max |
34.25 |
9.0 |
2.0 |
1.00 |
0.60 |
0.050 |
0.50 |
0.60 |
0.030 |
0.015 |
0.40 |
0.30 |
0.20 |
Physical properties for n06035
Density |
8.18 g/cm3 |
Melting range |
1332-1361℃ |
Features: Hastelloy G-35 n06035 is an upgrade version of Hastelloy G-30. It has extraordinary resistance in the wet process phosphoric acid production environment, which is widely used in fertilizer production. Its performance in this environment is far superior to Hastelloy G-30 and stainless steels. It can also resist localized corrosion and chloride-induced stress corrosion cracking in chlorides containing media. Because of its high chromium content, Hastelloy G-35 is extremely resistant to other oxidizing acids, such as nitric acid and mixtures containing nitric acid. As a result of its appreciable molybdenum content, it possesses moderate resistance to reducing acids, and unlike other nickel-chromium-molybdenum alloys, it is very resistant to caustic dealloying in hot sodium hydroxide.
Applications n06035: Wet process phosphoric acid production evaporators, pickling equipment using nitric acid and hydrofluoric acid, caustic neutralizing systems, and chemical process industry systems involving nitric acid and chlorides.
1. If we travel to China to checking your facility, are you welcome?
Of course, why not?
we will provide the whole accompany from you landing in China.
Only Give us a call before your arrive.
We will pick up you from the airport, living in our company's hotel, and driving by car take you visiting our company.
Warm Welcome!
2. How many sales person in your team?
present 8 sales, but more hands help in work, total team is 20+ workers.
So do not worry, not the one person company.
3. How Many Years of your company working in this industry?
We are 20+ years, from last century.
Expanding the market, and cultivate our techniques, two ways all in work together.
4. Could you show me some photos of your producing working?
here, following is our working plant, all is same when you come to China to audit.
we are locate in Shanghai. Building 32, No 518 XinZhuan Rd., Songjiang District, Shanghai, China
Postcode: 201601
Not matter where you come from, give us a call, we will pick up from the airport, station, etc.
Welcome take a visiting to our company!
Metro: Line 9, Jiu Ting Station
Train: HongQiao Station (22KM, take taxi 25 mins arriving at our company)
Bus: Shanghai Sourth Station (20KM, take taxi 20 mins arriving at our company)
Airplane:
From: PVG Airport (Shanghai Pudong Airport) only 50~53kilometer, by Taxi 50 mins arriving at our company,
From: Shanghai HongQiao Airport, 22KM, take 25 mins arriving at our company.
Standard export package with water proof paper, and metal pallet, and angle bar protection, and steel strip or as required
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
