LCD module
This LCD module is used with our Smart Li-ion BMS, as below picture shows:
Usage:
Firstly, connecting our BMS to electricity and work normally, 5 pins communication wires connect to LCD module and the other side of the wires connect to BMS communication port, as above picture shows.
LCD with 2 interfaces:
One shows individual cell real time voltage and cell qty, as below
Two shows total voltage and total capacity, charge/discharge status, etc, as below picture shows.
3 function keys in LCD module:
Key 1: show battery overall information
Key 2: show individual cell information
Key 3: turn off LCD power
Air cushion film packing + Foam filling + Double carton
Marking mode : Marking on the outer packing box
Shipping: TNT,FedEx,UPS,by plane,by sea
Fast reply your inquiry in 24 office working hours; OEM/ODM customized; design and produce the BMS and PCM as customer request
Our goal: to do first-class intelligent BSMS (lithium battery intelligent management system) solution provider
Shenzhen Smart Li-ion energy technology co., LTD started in 2011 committed to the development and promotion of LAPIS power protection solutions,successfully developed including 5 ~ 100 series of lithium battery intelligent control & management solutions, widely used in electric bicycles, electric motorcycles, cars, electric vehicles at low speed, the base station power supply, 4 g towers backup power supply system.
