GS6.6B 3d body analyzer
Testing data
1. Body composition: water content, protein, inorganic salt, bone mass
2. Musle fat analyzing: body weight, skeleton weight, fat weight.
3. Obesity analysis: weight, fat weight, WHR, water ratio, B.M.R
4. Obsesity diagnosis
5. Comprehensive assessment
6. Weight control
7. Exercise intensity
8. Dietary reference intake.
9. Health evaluation
SD card to save customers' information
Out-built printer
Body composition analyzer Technical data :
Input Power: 265V ~ AC90, 50HZ, 1A Output Power: DC5V, 3A +12 V/2A, -12V/0.2A Display Screen: Chinese and English 320 × 240 monochrome touchscreen Printer Interface: USB Compatible printers: HP DeskJet 5400 series Operating Environment: 10 to 40 , 30 ~ 80% RH, 500 ~ 600HPa Preservation of the environment: 10 to 40 , 30 ~ 80% RH, 500 ~ 600HPa Test weight range: 10 to 200 Kg Testing age range: 10 to 90-year-old
Body composition analyzer Warranty:
Despite careful testing of our equipment, component or functional failures may occur.
IBEAUY grants you a warranty as followed:
Our warranty period is 1 year. During our warranty, if any accessory failure happens, customers should provide us with failure report and we will provide free accessory for customers to replace, but customer should afford the freight charge.
While after warranty period, customers can purchase accessory from us and we will provide technical support.
Model |
GS6.5 Human Body Elements Analyser Equipment |
|||
Measuring method |
BIA via tetra-polar electrode method Using 8 touch electrodes Use 8 electrodes simultaneously among 8 electrodes by selecting feet electrode & hand electrode at system setup when using electrode option |
|||
Frequency range |
20KHz,50KHz,100KHz |
|||
Measuring site |
Whole body |
|||
Main Items |
Protein mass, Mineral mass, Mass of body fat, Total body water, Skeletal muscle mass, Lean body mass, Weight, B.M.I., Percent body fat, Basal metabolic rate, W.H.R. (Waist to Hip Ratio), Moisture Ratio, Obesity diagnosis, Nutritional assessment, Weight assessment, Obesity assessment, Goal weight, Weight control, Fat control, Muscle control, Health assessment, Bioelectrical impedance, Height(if it is interlocked with height measuring equipment /GS6.2). |
|||
Current |
<180uA |
|||
Power supply |
AC 100~240V, 50/60Hz |
|||
Display |
320*240 STN LCD touching screen |
|||
Input device |
Touch screen |
|||
Printing device |
USB port, printer |
|||
Dimension |
49*50*118cm in wooden case & 63*44*38cm in export case (package dimension) |
|||
NetWeight |
45KG |
|||
Measuring time |
Less than 2 minutes |
|||
Input height |
90-200CM |
|||
Measuring weight |
10-200KG |
|||
Applicable age |
10-99 years old |
|||
Operation ambient |
Temperature 10 ~ 40 °C, Humidity 30 ~ 80%RH,500-600hPa |
|||
Storage ambient |
Temperature 0~ 40 °C, Humidity 30 ~ 80%RH,500-600hPa |
|||
Option |
Ultrasonic height measuring equipment GS6.2 |
|||
