Home > Products > Digital LED pixel module > 12V 3pcs SMD5050 RGB LED programmable ws2811 led pixel module with housing
12V 3pcs SMD5050 RGB LED programmable ws2811 led pixel module with housing
- 10000 Piece / Pieces per Month
- Shenzhen/Hong Kong
- T/T Credit Card PayPal
You May Like
-
New coming DC5V 25mm 1LED RGB ws2811, sm16703, ucs1903 LED pixel module
-
New coming 12V 0.72W RGB color programmable LED pixel module light
-
44mm 6LEDs 5050 SMD 1.44W UCS2903 smart LED pixel RGB light
-
54mm 9LEDs SMD5050 2.16w UCS1903 smart LED pixel module light
-
68mm 18LEDs 24V 4.32W programmable UCS2903 RGB LED point light
-
DC5V RGB 60LEDs/m APA102/APA102C LED strip
Product Details
| Emitting Color | Tri-Color(Red-Blue-Green) | Luminous Intensity | 2000-2500MCD per LED | |
| Luminous Flux(lm) | 6-7m per LED | Optical Attenuation(%) | 3% | |
| Power | Other, 0.72w/pcs | Power Dissipation | 0.72W | |
| Color Rendering Index(Ra) | 80% | Color Temperature | RGB | |
| Operating Temperature(℃) | -30, 60 | Storage Temperature(℃) | -10, 40 | |
| Place of Origin | Guangdong, China | Brand Name | PACKEVER | |
| Certification | CE |
Product Description
12V 3pcs 5050 RGB LED programmable ws2811 led pixel module with housing
This item with beautiful shape housing outside! Different IC available, different housing available for 30mm LED pixel module!
Product Name | 12V 3pcs SMD5050 RGB LED programmable ws2811 led pixel module with housing |
LED type | SMD5050 RGB |
LED quantity | 3 pieces |
Work Voltage | DC12V |
IC Type | ws2811/ucs1903/sm16703/lpd6803/ws2801/dmx512 |
Power | 0.72W/pcs |
PCB Color | white |
Dimension | D30mm |
Waterproof | IP67 |
Work Temperature | -30-+60°C |
Life-span | 50,000H |
Certificate | CE&RoHS |
Warranty | 2 years |
12V 3pcs SMD5050 RGB LED programmable ws2811 led pixel module with housing Advantage:
1. Addressable, full color, each one can be controlled to show customized color
2. Can be connected by connector, easy to install
3. Rainproof, outdoor use
4. Beautiful shape
5. Use epistar chip LED to make sure long term use (if need other brand, please contact us)6. RGB and single color both available
12V 3pcs SMD5050 RGB LED programmable ws2811 led pixel module with housing Connection:
DC+: connect to power supply DC+
DAT: connect to controller DAT
CLK: connect to controller CLK (for ws2801, lpd6803 IC)
GND: connect to power supply GND & controller GND
We have more than 50 different items, if need more information, email or call us now! Accept customized design!
More 30mm size plastic housing pixel modules:
Automatic glue injection machines:
How to order:
1. Contact our sales. Our sales will quote for you based on your requirement;
2. Send you proforma invoice to confirm;
3. After confirmation your payment, we will arrange production
4. Goods sent out.
How to pay:
TT, Western Union, Paypal, Moneygram
How to send order:
Our sales will check with you which way to ship goods to you when making proforma invoice. Express, like DHL, FedEx, UPS, TNT, sea and air are available!
Warranty:
We are responsible company. We supply qualified products. All items have warranty time. Normally 2-3 years. When goods some defective, please contact our sales! If the problem was caused by us, we will remake or refund you.
