Flow Racking System

Name: Flow Racking System
Brand: EVERUNION
SKU: 126848455
Availability: InStock

US$ 10 - 100 MOQ: 10 Units

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

EVERUNION

Model Number:

PFR-01

Shanghai Everunion Logistics Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name EVERUNION

Model Number PFR-01

Type Selective Pallet Rack

Material Steel

Use Warehouse Rack

Certification Other, ISO9001:2008

Depth 1.8-2.5 mm

Weight Capacity 1-4tons/layer

Width 1200-3600mm

Height 2000-15000mm

Specifications

1. ISO9001: 2008 Certificated
2. 14years of experience
3. Customer's size accepted
4. CAD design for you indivadually

1) Facts about Flow rack

1.Products stored are "First In First Out"(FIFO)principle.

2.High storage density thus provide higher floor area utilization.

3.Picking & replenishment function can happen at the same time.

2) For quotation, kindly inform usthe info as below

- Drawing of racking or warehouse (ifavailable)

- Size of your warehouse (Length x Width xClear height)

- Size (W*D*H) & weight of pallet (afterloading),

- How many levels you would like

3) Everunion - Specificationsof pallet rack

Frame	Height (3-15m)	Depth (800-1,200mm)
	Upright section: 90 x 70; 100 x 90; 120 x80mm
	Thickness: 1.8/2.0/2.3/2.5mm
Beam	Length (1200-3600mm)
	Beam section: 80 x 50; 100 x 50; 120 x 50; 140 x 50mm
	Thickness: 1.5mm
Load capacity	1-4Tons/Layer
Others	- MOQ. 10 sets - Pitch: 75 or 76mm - Delivery time: 7-20days - Payment term. T/T (30% down payment) or L/C at sight - Necessary accessories: for free(bracing, base plate, etc) - Packing: stretch film & carton - Surface treatment: powder coated - Production capacity: 800T/month - Main market: exported more than 40countries, such as Australia, Europe, Asia, Central America, South America, North Africa and etc. - Available in various colors/specifications/sizes
