online pcb quote for quality multi layer printed circuit boards
- 1000 Square Meter / Square Meters per Month
- Shenzhen.Hongkong
- T/T Credit Card
- USB Relay Output Module PCB Board for Home Automation
- PCB Roger Circuit Board with cheap cost & Fast supply
- Cheap cost Rogers PCB production , pcb sample
- Fast Supply Rogers 4350 PCB Circuit Board Prototype and mass pcb production
- High quality Rogers Printed Circuit board with fast supply , rogers material in stock
- 2 layers Taconic Material PCb /Special material pcb circuit board provided
Product Details
Place of Origin: | Guangdong, China | Brand Name: | OEM | Model Number: | EW-OLPCB |
Number of Layers: | Other, 1-18 | Base Material: | FR4 | Copper Thickness: | 1oz |
Board Thickness: | 1.6mm | Min. Hole Size: | 0.25mm | Min. Line Width: | 0.075mm |
Min. Line Spacing: | 0.075mm | Surface Finishing: | Lead-free HASL |
Product Description
Specifications
pcb quote for quality multi layer printed circuit boards2Fast lead time
3ISO,ROHS,SGS,UL
4X-ray/AOI/function test
Welcome to Eastwin!
We are a professional OEM PCB&PCB assembly manufacturer for many years in China,with ISO9001:2008 Certification.We can manufacture and assemble all kinds of PCB/PCBA.Please send us your detailed specifications and we'll quote to you soon.
Eastwin PCB board manufacture and PCB Assembly services including belows:
PCB Design&Electronic PCB Manufacturer
* PCB board file with parts list provided by customers (Gerber file,PCB file,Eagle file or CAD file all acceptable)
* PCB board file will be checked by PCB engineer (Eastwin Engineer will study file and improve the design with suggestions)
* PCB board made, circuit board parts purchased by Eastwin (Eastwin will help to order aprroved file in short time)
* PCB board components sourced by Eastwin(Eastwin able to source the components as the parts list)
* PCB board with components assembled(Eastwin will help to make few samples first and when sample approved,the rest will be complete in really quite short time as requst)
* Electronic testing circuit board or PCBA(All the bare board will go through E-test and Function test for the PCBA)
* Fast delivery, anti-static package(Eastwin will help to offer more better packing methods to each projects and think more than you can imagine)
* RoHS Directive-compliant, lead-free(All the process has strict stardard, ISO9001:2008 )
* One stop service for PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery
(Eastwin can offer more service than you can imagine,just contact us when have needs!!!)
Part 1:Technical Specification For PCB
Number of Layer | 1,2,4 or 6,upto 18 layer |
Order Quantity | 1 to 50,000 |
Board Shape | Retangular,round,slots,cutouts,complex,irregular |
Board Type | Rigid, Flexible, Rigid-flexible |
Board Material | FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc. |
Board Cutting | Shear,V-score,Tab-routed |
Board Thickness | 0.2-4.0mm, Flex 0.01-0.25mm |
Copper Weight | 1.0, 1.5, 2.0 oz |
Solder Mask | Double-sided green LPI,Also support Red,White,Yellow,Blue,Black |
Silk Screen | Double-sided or single-sided in white,yellow,black,or negative |
Silk Screen Min Line Width | 0.006'' or 0.15mm |
Max Board Dimensions | 20 inch*20inch or 500mm*500mm |
Min Trace/Gap | 0.10mm, or 4mils |
Min Drill Hole Diameter | 0.01'',0.25mm, or 10mils |
Surface Finish | HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc. |
Board Thickness Tolerance | ±10% |
Copper Weight Tolerance | ± 0.25 oz |
Minimal Slot Width | 0.12'', 3.0mm, or 120mils |
V-Score Depth | 20-25% of board thickness |
Design File Formate | Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG |
♦ All of the above description is to demonstrate the ability of our factory,
if you have any specific requirements, please contact us.
Part2:Detailed Terms for Pcb Assembly
1.Technical requirement for pcb assembly: What we can do?
1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206,0805,0603,0402,0201 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.
2.Quote requirement for pcb and pcb assembly:
1)Gerber file and Bom list Gerber file,PCB file,Eagle file or CAD file all acceptable
2)Clear pics of pcba or pcba sample for us This will help a lot for the fast purchasing as request
3)Test method for PCBA This can guarantee 100% good quality products when delivered
3.Assembly Capabilities
· Printed Circuit Board Assembly (PCBA)
· Through Hole
· Surface Mount (SMT)
· PCB Handling up to 400mm x 500mm
· RoHS Compliance Production
· Non RoHS Production – where permitted
· AOI
4.Component Technologies
· Passive Down to 0201 size
· BGA and VFBGA
· Leadless Chip Carriers/CSP
· Fine Pitch to 0.8mils
· BGA Repair and Reball
· Part Removal and Replacement
5.Production Details:
1) Material Management
Supplier → Components Purchase → IQC → Protection Control → Material Supply → Firmware
2) Program Management
PCB Files → DCC → Program Organizing → Optimization → Checking
3) SMT Management
PCB Loader → Screen Printer → Checking → SMD Placement → Checking → Air Reflow → Vision Inspection → AOI → Keeping
4) PCBA Management
THT→Soldering Wave (Manual Welding) → Vision Inspection → ICT → Flash → FCT → Checking → Package → Shipment
Part3:How to release a order?
Part4:Packing&Shipping
Inner packing :Vacuum Package ;Outer packing:Standard Carton
Part5:View of our Factory!
Contact Us
- Shenzhen Eastwin Trading Ltd.
- Contact nameMike Smith
- Phone86-0755-23573370
- Address4 Floor,2 Building,Guanghui Technology Park,MinQing Road,Longhua,Shenzhen,China Shenzhen,Guangdong
Double-sided Pcb | Multilayer PCB | New Products | PCB & PCBA Spare Part |
PCB Samples | PCB&PCB Assembly | PCBA OEM Service | PCBA Samples |
Printed Circuit Board |
- Multilayer PCB
- Multilayer PCB manufacturer,4 – 16 layers standard, 24 layers advanced, 30 layers prototype, up to 100 layers
- Multilayer PCB,Multi layer HDIPCB
- Lead Free HASL Power heavy duty project
- Immersion Tin 4layer press fit hole board
- ENIG BGA PCB
- Immersion Tin PCB
- ENIG automobile reversing radar PCB
- ENIG Automotive ECU project PCB Board
- Motherboard 8 layer motherboard ENIG FR4 PCB
- Lead Free HASL PCB
- Automotive dashboard PCB
- Multilayer PCB
- Shenzhen FR4 circuit board rigid pcb led chip pcb board manufacturer PCBA
- Value Added Services Enclosure for printed circuit board PCBA manufacturer pcb & pcba
- FPC/ Flex PCB For LED Display
- Consumer Electronics FPC/ Flex PCB Manufacturing
- Custom Phone Battery FPC/ 4 Layer Flexible Printed Circuits
