LED Lighting Pcb Assembly/pcb Factory

LED Lighting Pcb Assembly/pcb Factory thumbnail-1
LED Lighting Pcb Assembly/pcb Factory photo-1
US$ 0.1 - 15 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
EW-30609S37
Contact Supplier Request Quote Chat Now
Shenzhen Eastwin Trading Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name OEM
Model Number EW-30609S37
Base Material Aluminum
Copper Thickness 1oz(35um)
Board Thickness 1.6mm
Min. Hole Size 0.25mm
Min. Line Width 0.075mm(3mil)
Min. Line Spacing 0.075mm(3mil)
Surface Finishing HASL

Specifications

1.Rigid pcb with smt,dip assembled
2.Automatic smt,dip lines for assembly
3.AOI,X-ray test,Function test
4.15-20 days

Welcome To Eastwin



Eastwin, your single point of contact for all of your raw materials, parts, and PCB assembly, also offers:



- Contract Manufacturing

- Engineering Services

- PCB Design & Assembly

- Product Design

- Prototyping

- Cable and Wire Assemblies

- Plastics and Molds



1.Detailed Specification of PCB Manufacturing



1

layer

1-18 layer

2

Material

FR-4,CEM-1,CEM-3,High TG,FR4 Halogen Free,FR-1,FR-2

3

Board thickness

0.2mm-4mm

4

Max. finished board side

800*508mm

5

Min. drilled hole size

0.25mm

6

min. line width

0.075mm(3mil)

7

min. line spacing

0.075mm(3mil)

8

Surface finish/treatment

HASL/HASL lead free, Chemical tin, Chemical Gold,

Immersion gold Immersion Silver/Gold, Osp, Gold Plating

9

Copper thickness

0.5-4.0oz

10

Solder mask color

green/black/white/red/blue/yellow

11

Inner packing

Vacuum packing, Plastic bag

12

Outer packing

standard carton packing

13

Hole tolerance

PTH:±0.076,NTPH:±0.05

14

Certificate

UL,ISO9001,ISO14001,ROHS,CQC

15

profiling punching

Routing,V-CUT,Beveling

16. providing OEM service to all sorts of printed circuit board assembly



2.Detailed Terms for Pcb Assembly



Technical requirement:

1) Professional Surface-mounting and Through-hole soldering Technology

2) Various sizes like 1206,0805,0603 components SMT technology

3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

4) PCB Assembly With UL,CE,FCC,Rohs Approval

5) Nitrogen gas reflow soldering technology for SMT.

6) High Standard SMT&Solder Assembly Line

7) High density interconnected board placement technology capacity.



Quote requirement:

  • Gerber file of the bare PCB board
  • BOM (Bill of material) for assembly
  • To short the lead time, please kindly advise us if there is any acceptable components substitution.
  • Testing Guide & Test Fixtures if necessary
  • Programming files & Programming tool if necessary
  • Schematic if necessary

OEM/ODM/EMS Services for PCBA:

  • PCBA, PCB assembly: SMT & PTH & BGA
  • PCBA and enclosure design
  • Components sourcing and purchasing
  • Quick prototyping
  • Plastic injection molding
  • Metal sheet stamping
  • Final assembly
  • Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
  • Custom clearance for material importing and product exporting

Orientronic PCB assembly Equipment:

  • SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4
  • Reflow Oven: FolunGwin FL-RX860
  • Wave Soldering Machine: FolunGwin ADS300
  • Automated Optical Inspection (AOI): Aleader ALD-H-350B
  • Fully Automatic SMT Stencil Printer: FolunGwin Win-5



3.View of our Factory







View of Assembled products



LED lighting pcb assembly/pcb factory



Why us?


Quality
Our UL/Rohs standards insure quality assemblies from start to finish. Whether it's a simple custom product or a complex turnkey production run, Moko will adhere to the highest quality standards.

--------------------------------------------------------------------------------

Capable
We offers the latest in assembly capabilities and qualifications insuring that quality is built into every product we produce.

--------------------------------------------------------------------------------

Experience
When it comes to your build you want a partner you can depend on. Our management team has over 10years of combined industry knowledge. Our engineering team has over 7 years experience.

--------------------------------------------------------------------------------

Protecting your interests
Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentiality contract and treat your important documentation as they would their own.

--------------------------------------------------------------------------------

Flexibility
We pride ourselves on our ability to custom tailor programs around our customers' needs. We take time

to listen to your unique business needs and then set out to surpass them.
