PCB FOR LED,LED FR4 PCB,94V LED PCB,LED PCB 94V0,FR4 94V0 PCB
EASTWIN OEM ELECTRONIC MANUFACTURER
CE&ROHS approved pcb design & Electronic PCB manufacturer,we are dedicate pcb marker with total solutions industral
Based in Shenzhen, Shenzhen Eastwin Ltd specialize in electronic design, PCB manufacture, PCB assembly, and component sourcing services, also could provide:
- PCB&PCBA Contract Manufacturing
- Reverse Engineering Services
- PCB Design and Assembly
- Component Procurement & Material Management
- Product Design
- Fast PCB&PCBA Prototyping
- Cable and Wire Assemblies
- Plastics and Molds
- AOI,X-Ray Testing, other Function Testing Service
PCB board products and PCB assembly services:
1.PCB Board Processing Capability:
1 |
Layers |
Single Sided,2 to 18 Layer |
2 |
Board material type |
FR4,CEM-1,CEM-3,ceramic substrate board, aluminum based board, high-Tg, Rogers and more |
3 |
Compound material lamination |
4 to 6 layers |
4 |
Maximum dimension |
610 x 1,100mm |
5 |
Dimension tolerance |
±0.13mm |
6 |
Board thickness coverage |
0.2 to 6.00mm |
7 |
Board thickness tolerance |
±10% |
8 |
DK thickness |
0.076 to 6.00mm |
9 |
Minimum line width |
0.10mm |
10 |
Minimum line space |
0.10mm |
11 |
Outer layer copper thickness |
8.75 to 175µm |
12 |
Inner layer copper thickness |
17.5 to 175µm |
13 |
Drilling hole diameter (mechanical drill) |
0.25 to 6.00mm |
14 |
Finished hole diameter (mechanical drill) |
0.20 to 6.00mm |
15 |
Hole diameter tolerance (mechanical drill) |
0.05mm |
16 |
Hole position tolerance (mechanical drill) |
0.075mm |
17 |
Laser drill hole size |
0.10mm |
18 |
Board thickness and hole diameter ratio |
10:1 |
19 |
Solder mask type |
Green, Yellow, Black, Purple, Blue, White and Red |
20 |
Minimum solder mask |
Ø0.10mm |
21 |
Minimum size of solder mask separation ring |
0.05mm |
22 |
Solder mask oil plug hole diameter |
0.25 to 0.60mm |
23 |
Impedance control tolerance |
±10% |
24 |
Surface finish |
Hot air level, ENIG, immersion silver, gold plating, immersion tin and gold finger |
♦ All of the above description is to demonstrate the ability of our factory, if you have specific requirements, please contact us.
Multilayer PCB Assemlby Capability
1. Size as 0402,0603,0805 components SMT technology;
2. High Accuracy surface mounting and through hole soldering technology;
3. Nitrogen gas reflow soldering technology;
4. ICT,AOI,X-RAY,FCT,test system for SMT technology;
5. Well trained labor.
1.What service can i get?
Estwin can provide PCB gerber file design,Copy and Clone,OEM and ODM service.
Not only produce PCB,PCB Assembly,but also Plastic Enclosure,and Complete products.
2.Are my design files secure when I send them to you?
To help copyright protected,your files are held in complete safety and security manage by one person.Eastwin rule nobody can share with any form include us.Nor 329000usd magin in alibaba will be punished.
3.Do Eastwin welcome small quantity orders/produce prototype PCBs/PCBAs?
Yes.Eastwin understand company development steps.Any standrad pcb/pcba order,we help you to work out.
4.What options exist for the thickness of copper?
0.5 oz, 1.0 oz, 1.5 oz, 2.0 oz, 2.5 oz, 3.0 oz, 3.5 oz, 4.0 oz, 4.5 oz and 5.0 oz.
5.What file formats do you accept for PCB assembly?
Gerber and CAMAutoCAD DXF, DWG formats.
6.PCB and PCBA Products Quote Requirement:
*Gerber file of the bare PCB board (Take sample prototype us if do pcb clone,if you only have ideas in you mind,tell us,the engineer will make your mind come true)
*BOM (Bill of material) for assembly (The component list on the pcb board )
*To short the lead time, please kindly advise us if there is any acceptable components substitution.(Tell us the delively time and give us components contract way so we can purchase the component more faster)
*Testing Guide & Test Fixtures if necessary (If you have test method,show us,if no,we do function test made by our engineer)
If any questions,contract us,we will inform you all details you want !
-----Eastwin Team Group
Sharpay
skype:mokoann
Linkedin:ann sharpay
WhatsApp:15013859096
