Multi-function Automatic Seed Cake Packing/Wrapping Machine
1.FFA model PLC control
2.With CE approved
3.Servo motor contol
FFA Multi-function seed cake packing machine/Flow packing machine Parameter
Model |
FFA-450/99 |
FFA-450/120 |
FFA-450/150 |
FFA-450/180 |
FFA-590/120 |
FFA-590/150 |
FFA-590/180 |
Max film width(m) |
450 |
450 |
450 |
450 |
590 |
590 |
590 |
Package rate(bag/min) |
30-220 |
30-220 |
30-220 |
30-220 |
30-200 |
30-200 |
30-200 |
|
Bag length(mm) |
70-450 |
70-450 |
90-450 |
100-450 |
80-450 |
90-450 |
100-450 |
Bag width(mm) |
10-150 |
10-150 |
10-150 |
10-200 |
10-200 |
10-200 |
10-200 |
Product height(mm) |
5-45 |
5-65 |
5-85 |
5-120 |
5-65 |
5-85 |
5-120 |
Power voltage(v) |
220 |
220 |
220 |
220 |
220 |
220 |
220 |
Total installed power(kw) |
3.5 |
3.6 |
3.6 |
3.6 |
4 |
4 |
4 |
Weight(kg) |
1000 |
1000 |
1000 |
1000 |
1200 |
1200 |
1200 |
Dimensions(LxWxH)mm |
5700*1050*1700 |
5700*1050*1700 |
5700*1050*1700 |
5700*1050*1700 |
5700*1250*1800 |
5700*1250*1800 |
5700*1250*1800 |
Feature
1. PLC controller, flexible bag length cutting, operator needn’t to adjust the unloading working, saving time and saving films.
2. Human-machine touch screen, Chinese or English displaying, convenient and quick parameter setting.
3. Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
Packed in two cartons,
Delivery time: 25 working days
Any interste you are welcome to visit us.
For more details, please contact us freely.
