Tablet packing machine
Japan technology and original drawings,Life time more than 15 years.
Qingdao FEIFAN Packing Machinery maily focus on R&D,producing,marketing and service of packing machines and related products
The top equipement in the tablet packing area with more than 20 years experiences.
Special design customized for pharmaceuticals such as capsule,tablets ,injection ,paper-plastic packages.
The principal of our company is Safety,Eco-friendy,High Efficiency and Cost-saving.
Specification:
FFC series packing machine,designed for package according to special request of bulk,soft,long stick shape products.Longitude sealing on top side of products,can avoid heating impact.Fitable for packaging heat-resistant products.Among which model FFC720/820,designed for super big products and assembly packaging,save packaging cost by tray-free packing.
Mechanical Features:
1. Bottom reel means the center sealing at top,in which way the product will not be impacted by the heating roller.
2. Imported PLCcontrol,with bilinggual languge in display .
3. Main machine structure ade of cold roller steel.
4. With photo mark monitor,packing accrately.
5. Tube sealer,with stable side sealing
6. Center sealing adopts closed circuit heating,eliminate packing error
7. AC moto attached converter for releasing step-less control.
8. Position stop function avoid film damage
9. Rotary cutters improve packing speed
10.Protection cover for safety of user
FFA450 Series |
450/99 |
450/120 |
450/150 |
450/180 |
Max Film Width (mm) |
450 |
450 |
450 |
450 |
Speed (Bag/ min) |
30-220 |
30-220 |
30-220 |
30-220 |
Packing Length (mm) |
70-450 |
70-450 |
90-450 |
100-450 |
Packing Width (mm) |
10-150 |
10-150 |
10-150 |
10-150 |
Packing Height (mm) |
5-45 |
5-65 |
5-85 |
5-120 |
Electric Power Voltage (v) |
220 |
220 |
220 |
220 |
Total Installed Power |
3.5 |
3.6 |
3.6 |
3.6 |
Weight (kg) |
1000 |
1000 |
1000 |
1000 |
Dimensions (L*W*H) (mm) |
5700*1050*1700 |
5700*1050*1700 |
5700*1050*1700 |
5700*1050*1700 |
Packing Material |
Paper/PE, OPP/PE, OPP/AL/PE, POF etc |
|||
FFA590 Series |
590/120 |
590/150 |
590/180 |
Max Film Width (mm) |
590 |
590 |
590 |
Speed (Bag/ min) |
30-200 |
30-200 |
30-200 |
Packing Length (mm) |
80-450 |
90-450 |
100-450 |
Packing Width (mm) |
10-200 |
10-200 |
10-200 |
Packing Height (mm) |
5-65 |
5-85 |
5-120 |
Electric Power Voltage (v) |
220 |
220 |
220 |
Total Installed Power |
4 |
4 |
4 |
Weight (kg) |
1200 |
1200 |
1200 |
Dimensions (L*W*H) (mm) |
5700*1250*1800 |
5700*1250*1800 |
5700*1250*1800 |
Packing Material |
Paper/PE, OPP/PE, OPP/AL/PE, POF etc |
||
Packing material:
Any heatmelt-cut sealing materials like Paper-PE,OPP/AL/PE,BOPP etc.
Application:
Mutiple bags of products,such as tablets,bread,instant noodles,Egg yolk pie,ham sausage and so on.
Remark:
Servo motor is optional,reduce reparing cost.
