high speed automatic cartoning machine
PLC and servo motor control
easy operate
Performance feature:
1. Automatic horizontal cartoning machine is a high-tech product, which is a integration of light, electricity, gas and machine.
2. It's suitable for blister forming capsule and tablet, aluminum-plastic packed blister board and similar items into cartons automatically.
3. Working process: medicine plate or other items transmission ( adjustable if more than one plate)
-- drugs manual transmission (to automatically finish 1-4 folding) -- carton automatic distraction and delivery--plate joint folded manual into carton -- automatic batch number printing, paper tongues sealing on both ends, etc.
4. Machine use high quality stainless steel casing shape, working faces are closed by organic glass door and windows. It's innovatively designed, strictly in accordance with requirements of pharmaceutical industry "GMP" standard.
5. Product height is not standard, auto rejecting when no instruction book.
6. Auto stopping machine when product does not enter carton completely.
7. Auto stopping machine when no carton, no continuous instruction book or no product.
8. Convenient to change products with different specification.
9. Main drive is equipped with overload protection device.
10. PLC automatic display failure, box packing speed and finished counting
Technical parameters:
Model |
FF-120WZ |
|
Capacity |
30-100 boxes/min |
|
Power supply |
1ph. 220V, 50/60Hz |
|
Main motor power |
0.75 KW |
|
Gas consumption |
120-160L/min (Pressure 0.6Mpa) |
|
Packing material |
Carton specification 250-350g/m2 (Depends on carton size) |
|
Specification |
L(701-180)mm x W(35-85)mm x H(14-50)mm |
|
Instruction book |
Paper specification |
60-70g/m2 |
Unfolding size |
L(80-250)mm x W(90-170)mm |
|
Folding range |
Customized |
|
The number of folding |
1-4 |
|
Net weight |
About 1400kg |
|
Overall Dimension |
L3100 x W1100 x H1550mm |
|
