JY-30 Single Phase Sealed and Busbar Current Transformer(ct) 5a

JY-30 Single Phase Sealed and Busbar Current Transformer(ct) 5a thumbnail-1
JY-30 Single Phase Sealed and Busbar Current Transformer(ct) 5a photo-1
US$ 2.5 - 12.5 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Beier
Model Number:
JY-30
Contact Supplier Request Quote Chat Now
Yueqing Beier Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Beier
Model Number JY-30
Usage Instrument
Phase Single
Coil Structure Toroidal
Coil Number Autotransformer
Company Information

JY-30 single phase sealed and busbar current transformer(ct) 5a

Product Description

JY-30 single phase sealed and busbar current transformer(ct) 5a

 1. Standard: IEC44-1, BS3938, DIN42600, GB1208-2006;

2. Primary current:50-800A;

3. Secondary current:1.5- 2.5A;

4. Accuracy class: 3.0,1.0,0.5 (Class0.2 or class0.2S can be tailor made!)

5. Cases are made of ABS, meet UL-94V0;

6. Short -time thermal current: Ith=60x1h;

7. Security factor: FS less than 5

JY-30 single phase sealed and busbar current transformer(ct) 5a



JY-30 single phase sealed and busbar current transformer(ct) 5a

Feature

 JY-30 single phase sealed and busbar current transformer(ct) 5aJY-30 single phase sealed and busbar current transformer(ct) 5a





Packaging & Shipping

 JY-30 single phase sealed and busbar current transformer(ct) 5a

Advantages



  • All the cases are made of polycarbonated materials, not ABS    material case,so the temperature endurence is much higher;



  • All the cores are made of imported highest quality silicon iron sheet,so the core's magnetic performance is much higher;



  • All the parameters are double cross-checked, so the testing results is much ensured!
Certifications

 JY-30 single phase sealed and busbar current transformer(ct) 5aJY-30 single phase sealed and busbar current transformer(ct) 5a
